GE IS200EDEXG1BAA Exciter De-Excitation Control Board for Mark V
GE IS200EDEXG1BAA Exciter De-Excitation Control Board for Mark V
GE IS200EDEXG1BAA Exciter De-Excitation Control Board for Mark V
GE IS200EDEXG1BAA Exciter De-Excitation Control Board for Mark V
GE IS200EDEXG1BAA Exciter De-Excitation Control Board for Mark V
GE IS200EDEXG1BAA Exciter De-Excitation Control Board for Mark V
GE IS200EDEXG1BAA Exciter De-Excitation Control Board for Mark V
GE IS200EDEXG1BAA Exciter De-Excitation Control Board for Mark V
Specifications
Brand Name :
GE
Model Number :
IS200EDEXG1BAA
Certification :
COO
Place of Origin :
USA
MOQ :
1
Price :
$2500
Payment Terms :
T/T
Supply Ability :
999
Delivery Time :
5-7days
Name :
GE IS200EDEXG1BAA Exciter De-Excitation Control Board
Product ID :
IS200EDEXG1BAA
Series :
Mark V
Product Net Width :
100mm
Product Net Height :
200mm
Product Net Weight :
2kg
Product Net Depth/Length :
330mm
Warranty :
1 Year
Description

GE IS200EDEXG1BAA Exciter De-Excitation Control Board


Product Description:

The GE IS200EDEXG1BAA is an Exciter De-Excitation Control Board (EDEX) in the EX2100e excitation system, critical for generator safety during emergency shutdowns. Its primary role is to dissipate stored energy from the generator field when field breakers or contactors open, preventing damage. Integral to the de-excitation module, it works with the EMIO and EXTB boards to trigger and execute energy dissipation via controlled Silicon Controlled Rectifier (SCR) firing.


Equipped with Hall Effect conduction sensors, voltage hold-up circuits, and status LEDs, it ensures reliable operation even during power failures. The board processes current signals, maintains essential voltage rails, and coordinates with auxiliary components to enable precise, uninterrupted de-excitation in generators.


Features:
SCR Control: Manages SCR firing to regulate current flow and efficiently dissipate generator field energy during shutdowns.


Conduction Feedback: Uses Hall Effect sensors with a magnetic coupling ring to detect bipolar current flow, transmitting signals M1/M2 to the EXTB board for monitoring and control.


Voltage Retention: A hold-up circuit maintains ±24V DC rails during power failures, ensuring SCR firing and external contact functionality for uninterrupted de-excitation.


EMIO Initiation: Triggered by the EMIO board via the EXTB, it coordinates contactor/breaker opening and signal transfer to SCR circuits.


Status Indicators: Two red LEDs illuminate during current detection, providing visual feedback on conduction sensor operation for diagnostics.


GE IS200EDEXG1BAA Exciter De-Excitation Control Board for Mark V

GE IS200EDEXG1BAA Exciter De-Excitation Control Board for Mark V
