The 3500/40M 176449‑01 is a four‑channel monitor card that processes signals from non‑contact sensors to provide accurate vibration and shaft position measurement data. Channels can be configured in pairs to monitor different machine conditions, with user‑definable warning limits that trigger alerts when readings exceed safe levels. The unit transmits machine status data to central control computers, enabling continuous online protection for rotating equipment.

Key parameters and real‑world value:

1. Measurement accuracy ±0.5% full‑scale｜Value: Small measurement error helps catch tiny early machine problems.
2. Response time ≤500μs｜Value: Reacts very fast to sudden vibration or position changes, to meet safety control needs for large industrial machines.
3. Working temperature ‑40℃ ~ +85℃｜Value: Runs reliably in hot control rooms and seaside factory sites, keeps stable readings in wide temperature ranges.

• Early Fault Warning – Continuous monitoring of vibration and shaft movement provides warnings before component failure, reducing the risk of unexpected shutdowns
• Machine Safety Control – Integration with plant safety systems protects high‑value rotating machinery when readings reach dangerous levels
• Digital Machine Record‑Keeping – Standardized measurement data enables trend analysis and condition‑based maintenance, eliminating unnecessary maintenance work
• Space‑Saving Multi‑Channel Design – Single unit supports four sensor inputs, reducing hardware requirements and associated costs for purchasing, wiring, and maintenance

Our field engineers recommend verifying the complete sensor connection setup before commissioning the 3500/40M 176449‑01. Incorrect cable lengths can produce inaccurate measurement results. For high‑speed compressor applications, configure separate channel groups for vibration and shaft position monitoring. Avoid mixing monitoring functions within single channel groups to ensure proper warning signal operation.
