24V DC Mitsubishi HMI 10 Inch GS2110-WTBD TFT Color LCD Touch Panel
24V DC Mitsubishi HMI 10 Inch GS2110-WTBD TFT Color LCD Touch Panel
24V DC Mitsubishi HMI 10 Inch GS2110-WTBD TFT Color LCD Touch Panel
24V DC Mitsubishi HMI 10 Inch GS2110-WTBD TFT Color LCD Touch Panel
Specifications
Place of Origin :
China/Japan
Brand Name :
Mitsubishi
Model Number :
GS2110-WTBD
Packaging Details :
Carton packaging
Supply Ability :
10pc/per week
Price :
$120-$800
MOQ :
1/pc
Payment Terms :
T/T, western union
Condition :
100% Original
Warranty :
1 Year
Shipping term :
TNT DHL FEDEX EMS UPS
Quality :
100%Brand
Type :
Human Machine interface
Payment term :
T.T WESTUNION
Delivery time :
Within 3 Working Days
Package :
100% Original Package
Model :
GS2110-WTBD
Brand :
Mitsubishi
Port :
Guangdong Shenzhen Dongguan
Description

Original new 10 inch Mitsubishi GS2110-WTBD HMI touch panel

24V DC Mitsubishi HMI 10 Inch GS2110-WTBD TFT Color LCD Touch Panel

Specification

7″ Mitsubishi Touch screen HMIs GS21 Simple GS2110-WTBD GS2107-WTBD
Display Device TFT color LCD
Screen Size 10″ 7″
Resolution 800 x 480 dots
Display Size(W x H) mm (inch) 222 x 132.5 (8.74 x 5.22) (Horizontal format) 154 x 85.9 (6.06 x 3.38) (Horizontal format)
Number of Characters 16-dot standard font: 50 chars. x 30 lines (2-byte) (Horizontal format)
Display Color 65536 colors
Backlight LED (not replaceable) Backlight off/screen saving time can be set
Touch Panel Type Analog resistive film
Key Size Minimum 2 x 2 dots (per key)
Simultaneous Press Simultaneous press prohibited (only 1 point can be pressed)
Life 1 million times (operating force 0.98N or less)
Memory C Drive Flash memory (internal) (9MB), for storing project data, OS Life (No. of writings) 100000 times
Built-in Interface RS-422 RS-422, 1chTransmission speed: 115200/57600/38400/19200/9600/4800bps Connector shape: D-Sub 9pin (female)Application: For communication with controllers Terminating resister: 330 Ω fixed
RS-232 RS-232, 1chTransmission speed: 115200/57600/38400/19200/9600/4800bps Connector shape: D-Sub 9pin (male)Application: For communication with controllers and a barcode readerFor connecting a personal computer (Project data read/write, FA transparent function)
Ethernet Data transfer method: 100BASE-TX, 10BASE-T, 1ch Connector shape: RJ-45 (modular jack) Application: For communication with controllersFor connecting a personal computer (Project data read/write, FA transparent function)
USB USB (Full Speed 12Mbps), 1ch Connector shape: Mini-BApplication: For connecting a personal computer (Project data read/write, FA transparent function)
SD Card SD compliant, 1chSupported memory card: SDHC memory card, SD memory card Application: Project data read/write, logging data save
Buzzer Output Single tone (LONG/SHORT/OFF adjustable)
Protective Structure IP65F (Only the front part of the panel)
Ext. Dimensions (W x H x D) mm (inch) 272 x 214 x 56 (10.71 x 8.43 x 2.21) 206 x 155 x 50 (8.11 x 6.11 x 1.97)
Weight (Excl. Mounting Brackets) (kg) 1.3 0.9
Compatible Software Package GT Designer3 Version1.105K or later (*1) (English Version)
Mitsubishi touch screen HMI GS21 Power Supply GS2110-WTBD GS2107-WTBD
Power Supply Voltage 24VDC (+10%, -15%), ripple voltage 200mV or less
Power Consumption 7.6W (317mA/24V) or less 6.5W (271mA/24V) or less
With Backlight Off 3.8W (158mA/24V) or less 3.8W (158mA/24V) or less
Inrush Current 17A or less (6ms, ambient temperature 25, maximum load)
Allowable Momentary Power Failure Time Within 5ms
Noise Immunity Conforms to IEC61000-4-4, 2kV (power supply line)
Withstand Voltage 350VAC for 1 minute between power supply and ground
Insulation Resistance 10MΩ or higher with an insulation resistance tester (500VDC between power supply terminal and ground)
