6ES7972-0BB12-0XA0 Siemens SIMATIC DP Communication Wire Connector

Alibaba Web : https://shkautomation.en.alibaba.com

Description :

SIMATIC DP, Connection plug for PROFIBUS up to 12 Mbit/s 90° cable outlet, 15.8x 64x 35.6 mm (WxHxD), terminating resistor with isolating function, With PG receptacle.

Frequently bought together:6ES7972-0BB42-0XA0

Description :

SIMATIC DP, Connection plug for PROFIBUS up to 12 Mbit/s with inclined cable outlet, 15.8x 54x 39.5 mm (WxHxD), terminating resistor with isolating function, With PG receptacle.

6ES7972-0BB12-0XA0 6ES7972-0BB42-0XA0

The functions of Siemens connectors mainly include the following aspects
1. Various types of bus connectors are provided to optimize the connection of devices. These connectors

have an axial cable outlet (180°) and a vertical cable outlet (90°) for data transfer rates up to 12 Mbit/s.

They also come with integrated bus termination resistors that help improve data transfer efficiency and stability.

2. Support a variety of data transmission rates, select the appropriate connector as required. For example,

when the data transfer rate is 3, 6, or 12 Mbit/s, the SIMATIC S5/S7 connection cable can be used to connect between the bus connector with the programmer interface and the programmer. The economical 30° cable

outlet bus connector has no programmer interface and data transfer rate up to 1.5 Mbit/s, but has no

integrated bus termination resistance.

3. Support PROFIBUS fast connection, use RS485 bus connector, transmission rate up to 12 Mbit/s. The insulation puncture technology makes the installation process quick and easy, and is suitable for hard and

flexible wire connections. The bus connector can be plugged directly into a PROFIBUS station or PROFIBUS interface (9-pin Sub-D interface) of a PROFIBUS network component. Four terminals can be used in the

plug to connect the incoming and outgoing PROFIBUS cables. The integrated bus terminator is connected

via an externally visible and easily accessible switch, the incoming and outgoing bus cables are separate,

with isolation functions1 In summary, Siemens connectors provide multiple types of bus connectors and

support multiple data transfer rates, as well as PROFIBUS fast connection capabilities. It provides efficient

and reliable connectivity solutions for industrial automation.
