A7 Series Gasket Plate Heat Exchanger Carbon Steel For Chemical HVAC Electronic Industry

Specifications

Brand Name :

Tenkai

Model Number :

Certification :

ISO9001-2015

Place of Origin :

CHINA

MOQ :

1 wooden package

Price :

Negotiate

Payment Terms :

L/C, T/T, D/P, Western Union

Supply Ability :

150pcs/Day

Delivery Time :

Within 10 days

Packaging Details :

Wooden Box Package

Material :

Carbon Steel

Max Design Pressure :

1.5 Mpa

Connection Mode :

Clamp,Flange,External thread

Warranty Period :

One year

Structure :

Gasketed

HS CODE :

8419500090

Application :

HVAC Industry/Chemical/Electronic Industry

Max Pressure :

16KG

Description

A7 Series Gasket Plate Heat Exchanger Carbon Steel Material For Chemical HVAC Electronic Industry

Introduction :

Detachable Plate Heat Exchanger is a heat transfer device that consists of a series of individual plates that can be easily disassembled and reassembled. Each plate has special patterns that create flow channels for the hot and cold fluids, allowing efficient heat exchange to occur. The detachable design offers flexibility for maintenance, cleaning, and modifications.

Product Features:

Easy Disassembly and Reassembly: The detachable plate heat exchanger allows for convenient access to the individual plates, facilitating cleaning, maintenance, and inspection operations.
High Heat Transfer Efficiency: The special patterns on the plates promote turbulent flow and maximize the heat transfer surface area, resulting in efficient heat exchange and improved performance.
Compact Design: The compact arrangement of the plates enables a large heat transfer surface area within a small footprint, making it suitable for applications where space is limited.
Flexibility and Scalability: The modular design allows for easy customization and expansion by adding or removing plates to meet specific heat transfer requirements.
Versatile Applications: Detachable plate heat exchangers are widely used in various industries, including HVAC systems, refrigeration, food processing, chemical processing, power generation, and oil and gas industries.

TYPE	A(mm)	B(mm)	C(mm	D(mm)	E(mm)	Height ( mm ) ( from middle of bottom to ground ) (mm)	MAX.LC (mm)	Connector Path ( mm ) (mm)	Max Flow ( m3/h ) (m3/h)	Design Pressure (Mpa)	Max Pieces
A8	N(2.3+X)	200	70	750	656	51.5	500	28	18	10/1.6	95
A7	N(2.3+X)	300	126	660	394	160	500	60	36	1.0/1.6	200
A14	N(2.3+X)	300	126	960	694	160	1200	60	36	1.0/1.6	200
A19	N(2.3+X)	382	192	995	701	165	1200	66	36	10/1.6	250
