Specifications
Brand Name :
Antai
Model Number :
C11000 C10100 C10200 C1100
Certification :
SGS
Place of Origin :
China
MOQ :
1 TON
Price :
Usd8600/ton
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
5000 Ton Per Month
Delivery Time :
10 days
Packaging Details :
Standard export packaging
Shape: :
plate
Cu (Min): :
99.9
Ultimate Strength (≥ MPa): :
371
Payment Term: :
L/C T/T (30%DEPOSIT) western union
Size: :
as customized
Width: :
20-1000mm or as reqwuired
Alloy Or Not: :
Non-Alloy
Elongation (≥ %): :
31
Processing Service: :
Bending, Welding, Decoiling, Cutting, Punching
Surface: :
Polished
Sample :
Available
Standard: :
JIS ASTM DIN EN ISO
Description

Customized 99.99 Pure Bronze Copper Sheet C11000 C10100 C10200 C1100 Metal / Pure Copper Plate

Product Name ASTM Copper Sheet / Copper Plate
Material

C10100,C10200,C10300,C10400,C10500,C10700,C10800,

C10910,C10920,C10930,C11000,C11300,C11400,C11500,C11600,

C12000,C12200,C12300,C12500,C14200,C14420,C14500,C14510,

C14520,C14530,C17200,C19200,C21000,C23000,C26000,C27000,

C27400,C28000,C33000,C33200,C37000,C44300,C44400,C44500,

C60800,C63020,C65500,C68700,C70400

Shape Flat plate . Flat bar , Strip, Coil
Standard DIN GB ISO JIS BA ANSI
Grade Thickness 0.3mm~100mm; Width 50mm~2500mm; Length 1000mm~12000mm
Payment T/T,L/C,western union, Paypal
Price Term CFR,FOB,CIF,Ex-work,CNF
Used

1) Further making utensil.

2) Solar reflective film

3) The appearance of the building

4) Interior decorating:ceilings,walls,etc.

5) Furniture cabinets

6) Elevator decoraction

7) Signs,nameplate,bags making.

8) Decorated inside and outside the car

9)Household appliances:refrigerators,microwave ovens,audio

Alloy Grade Material Characteristics Application

C11000
Cu≥99.90

It has good electrical conductivity, heat conduction, corrosion resistance and processing properties. It can be welded and brazed.
The impurities and trace amount of oxygen only have very few effect on electrical and thermal conductivity. But the trace oxygen is easy to cause "hydrogen disease", so it can’t be processed and used in high temperature (such as > 370℃).

Widely used for electric, heat conduction, corrosion resistance equipment. Such as: wire, cable, conductive screw, blasting
detonator, chemical evaporator, storage device and a variety of pipes etc.

C10200
Cu≥99.97

C10300
Cu≥99.95

High purity, excellent electrical and thermal conductivity, barely no "hydrogen disease", good processing, welding, corrosion
resistance and cold resistance performance.

Mainly used for electrical vacuum instruments, all kinds of hardware products, lamps, pipe fittings, zippers, plaques, nails, springs, sedimentation filters etc.

C12000,C12200
Cu≥99.90

Good welding and cold bending performance. It can be processed and used in reducing atmosphere, but not in oxidizing atmosphere.
C12000 has less residual phosphorus than C12200, so its thermal conductivity are higher than C12200.

Mainly used for pipe applications, such as gasoline or gas conveying pipe, drain pipe, condensate pipe, mine pipe, condenser, evaporator, heat exchanger, train parts. It also can be processed to plate, strip, tape and rod.


DIN ISO JIS 99.9 Pure Copper Sheet C11000 C10100 C10200 Material
DIN ISO JIS 99.9 Pure Copper Sheet C11000 C10100 C10200 Material
