Weatherproof Carbon Steel Metals Sheet With Polished Sand Blasting Surface
Weatherproof Carbon Steel Metals Sheet With Polished Sand Blasting Surface
Weatherproof Carbon Steel Metals Sheet With Polished Sand Blasting Surface
Weatherproof Carbon Steel Metals Sheet With Polished Sand Blasting Surface
Weatherproof Carbon Steel Metals Sheet With Polished Sand Blasting Surface
Weatherproof Carbon Steel Metals Sheet With Polished Sand Blasting Surface
Weatherproof Carbon Steel Metals Sheet With Polished Sand Blasting Surface
Weatherproof Carbon Steel Metals Sheet With Polished Sand Blasting Surface
Weatherproof Carbon Steel Metals Sheet With Polished Sand Blasting Surface
Weatherproof Carbon Steel Metals Sheet With Polished Sand Blasting Surface
Specifications
Brand Name :
Antai
Model Number :
Q235B
Certification :
SGS
Place of Origin :
China
MOQ :
1 TON
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
5000 Ton Per Month
Delivery Time :
10 days
Packaging Details :
Standard export packaging
Standard: :
AiSi, ASTM, bs, DIN, GB, JIS
Model Number: :
ar500 wear resistant steel plate
Technique: :
Hot Rolled, Hot Rolled
Width: :
200-3000mm
Tolerance: :
±1%
Type: :
Steel Plate, Cold Rolled Steel Sheet, wear plate
Surface Treatment: :
HRAP , hot rolled pickled , polished , sand blasting
Length: :
1000-12000m or as Your Request
Processing Service: :
Bending, Welding, Decoiling, Cutting, Punching
Payment term: :
30%TT+70% balance
Description

Weatherproof Steel Q235B External Waterproof Landscape Plate Weatherproof Corten Weatherproof Plate

Standard
Grade
ASTM: Corten A; Corten B; A588Gr.A/Gr.B/Gr.C/ Gr.K; A242; A606 Type 4; A709 Gr 50W;
EN10025: S235J0W; S235J2W; S355J0W; S355J2W; S355K2W; S355J0WP; S355J2WP; S355J2G1W; S355J2G2W; S355K2G1W, S355K2G2W;
JIS G3114: SMA400AW; SMA400BW; SMA400CW; SMA490AW; SMA490BW; SMA490CW; SMA570W; SMA570P;JIS G3125: SPA-H; SPA-C;
GB/T 4171: Q235NH; Q265GNH; Q310GNH; Q295NH; Q295GNH; Q355NH; Q355GNH; Q415NH; Q460NH; 1500NH; Q550NH;
TB/T 1979: 09CuPCrNi-A; 09CuCrNi-B; 05CuPCrNi;Q/BQB 340: B460NQR; B490NQR; B480GNQR; B600GNQR;

Grade
Thickness
Tensile Test (Transverse)
Brinell hardness
Impact test
90° bending test
Yield Strength
ReH,MPa
Tensile strength
Rm.MPa
Elongation A50mm,%
HBW
impact value (-40℃) KV2, J
temperature °C
Bending diameter
NM360
3-14mm
≥900
≥1100
≥12
360±30
≥20
-40
d = 5a
NM400
3-14mm
≥960
≥1200
≥10
400±30
≥20
-40
d = 5a
NM450
3-14mm
≥1100
≥1300
≥8
450±30
≥20
-40
d = 6a
NM500
3-14mm
≥1250
≥1450
≥8
500±30
≥20
-40
d = 8a
NM600
3-12mm
-
-
-
600±30
≥20
-40
-
NMS1400
3-15mm
≥1100
≥1350
≥8
450±30
≥20
-40
d = 7a
NMS1500
3-15mm
≥1250
≥1450
≥7
500±30
≥20
-40
d = 8a
NM300TP
3-8mm
550-850
≥950
≥8
270-380
≥20
-20
d = 6a
NM400TP
3-8mm
700-1000
≥1200
≥8
370-450
≥20
-20
d = 6a

Grade
Available thickness
Available width
Available length
NM360
3-14mm
850-1800mm
4000-12000mm
NM400
NM450
NM500
NM600
NMS1400
3-15mm
1000-1800mm
4000-12000mm
NMS1500
NM300TP
3-8mm
800-1600mm
4000-12000mm
NM400TP
