Specifications
Brand Name :
WX
Model Number :
660*300mm
Certification :
CE
Place of Origin :
made in China
MOQ :
1SET
Price :
25714
Payment Terms :
L/C,T/T
Supply Ability :
1
Delivery Time :
30Days
Packaging Details :
4300*1500*2200mm
Processing Type :
Heating, Forming, Cutting Into One
Dimensions :
4100*1500*2200mm
Water consumption :
60-70L/min
Use air pressure :
0.7-1.0Mpa
Control System :
PLC, Gear
core components :
PLC
key selling points :
Easy To Operate
Molding area :
660*300mm
Machine Status :
New
Description

Application:

Cup making machines can produce a variety of plastic container products, mainly including but
not limited to the following categories:1.Plastic cups: including disposable plastic cups, suitable for cold drinks, fast food, hot drinks and
other applications
2.Jelly cups: plastic containers for packaging jelly and other dessertsPackaging containers: plastic packaging containers for various products, such as food, beverages.etc.
3.Beverage cups: plastic cups especially suitable for holding various beveragesEnvironmentally friendly cups and packaging: For companies seeking green and environmental4.protection, cup making machines can also use biodegradable plastic materials such as PLA(polylactic acid) to produce environmentally

Technical Parameters:


Model: WX-720 WX-730 WX-750
Applicable sheet: PP,PS,PET,PVC,PLA etc
Applicable material width: ≤730mm ≤750mm ≤750mm
Applicable material thickness: 0.15-2.5mm
Maximum forming area: 420X730mm 450X750mm 550X750mm
Maximum stroke: 200mm
Working efficiency: <30Module/minute <28Module/minute
Maximum heating power: 95kw 110kw 110kw
Power supply: 380V/50HZ(Three-phase four-wire)
Air pressure: 0.6-0.8Mpa
Air consumption: 3000L
Water consumption: 40-45L/min
Mechanical dimensions: 4100X1500X2200mm 4300X1500X2200mm
Machine weight: 5500kg 6000kg 7000kg

Sample:

High speed plastic mini cup making machine

Machine photos:

High speed plastic mini cup making machine High speed plastic mini cup making machine

Support and Services:

Our Product Technical Support and Services for the Plastic Thermoforming Machine include:

- Installation assistance

- Training for machine operation and maintenance

- Troubleshooting guidance

- Spare parts ordering and replacement

- Regular maintenance and servicing options

Packing and Shipping:

Product Packaging:

The Plastic Thermoforming Machine is carefully packaged to ensure safe delivery. It is securely wrapped in protective materials and placed in a sturdy cardboard box to prevent any damage during transit.

Shipping:

We offer reliable shipping services for the Plastic Thermoforming Machine. Once your order is processed, the machine will be dispatched promptly to your specified address. You can track your shipment using the provided tracking number to monitor its delivery status.




FAQ:

Q: What is the brand name of this Plastic Thermoforming Machine?

A: The brand name is WX.

Q: What is the model number of this Plastic Thermoforming Machine?

A: The model number is 660*300mm.

Q: Where is this Plastic Thermoforming Machine made?

A: It is made in China.

Q: Does this Plastic Thermoforming Machine have any certification?

A: Yes, it is CE certified.

Q: What is the minimum order quantity for this Plastic Thermoforming Machine?

A: The minimum order quantity is 1 set.

Q: What is the delivery time for this Plastic Thermoforming Machine?

A: The delivery time is 30 days.
