High Precision Overmolding Mold Efficient Injection Molding Mould
High Precision Overmolding Mold Efficient Injection Molding Mould
High Precision Overmolding Mold Efficient Injection Molding Mould
High Precision Overmolding Mold Efficient Injection Molding Mould
High Precision Overmolding Mold Efficient Injection Molding Mould
High Precision Overmolding Mold Efficient Injection Molding Mould
Specifications
Brand Name :
MID MOULD
Place of Origin :
Dongguan, China
MOQ :
1 set
Payment Terms :
50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment
Delivery Time :
25–45 working days (longer for complex tools)
Certification :
ISO9001,FDA,ISO13485
Price :
USD $3,000–$50,000 per set (depending on complexity)
Packaging Details :
Wooden case + anti-rust oil + protective film + packing list
Supply Ability :
20–35 sets per month, depending on structure
Product name :
Overmolding Mold
Shaping mode :
Plastic Injection Mould,Plastic injection molding,Compression Mould
Material :
STEEL,ps,PP,Steel and metal,aluminum
Product :
Vehicle Mould,Household Appliance,plastic injection mold,injection machine mold,Household Product
Mould life :
250000-300000shots,200~1 M available,300,000shots,000 times
Runner :
Hot Runner\ Cold Runner,cold/hot
Cavity :
Multi Cavity,as per client's requirement
Product material :
Plastic,Steel,PP,ABS,PS
Mold material :
NAK80,H13,50#,P20,45#
Design software :
CAD,CAD/ProE/UG/SOLIDWORKS,CAD UG Moldflow,Solidworks,PROE
Mould material :
P20/718/738/NAK80/S136,P20/718/2738/H13/S136/NAK80,718,SKD61 etc,H13
Application :
Home Appliance,Industrial,Automotive,various range,Machine
Mould base :
non-Standard plastic injection mould,World standard,European standard,LKM.HASCO,HASCO standard
Surface treatment :
sandblasted,Texture,anodizing black,clear painting,Polishing
Size :
as samples/drawings,customized accepted,Customized Size
Mold runner :
Hot&Cold runner you can choose,Hot runner and code runner
Mold life :
000 to 1,500000 shots,000 shots,100000-1000000,50
Plastic material :
Peek,ABS/PP/PS/PE/PVC/PA6/PA66..et,MC Nylon,Derlin,UHMW-PE
Description
Product Process:

Overmolding uses a secondary injection molding process to coat a hard substrate with a soft material, enhancing the product's slip resistance, aesthetics, and comfort. This process is suitable for the production of high-end plastic parts.

Process Flow:
  1. Mold Structure Design and Analysis
  2. Mold Flow Analysis Verifies Overmolding Effect
  3. CNC High-Precision Cavity Machining
  4. Assembly of Cooling System and Positioning Structure
  5. Mold Trial and Performance Testing
Product Specifications:
Item Parameter Description
Mold Type Overmolded Injection Mold
Mold Material S136 718H H13
Number of Cavities 2–12
Mold Life 600,000–1.2 Million Cycles
Surface Treatment Polishing, Sandblasting, Chrome Plating
Applicable Materials PC ABS PP + TPE TPU
Overmolding Method Overmolding, Thermal Bonding
Product Accuracy ±0.02mm
Cooling System High-Efficiency Water-Cooled Parallel System
Production Cycle 50–80 Days
Product Advantages:
  • Beautiful Appearance, Comfortable Handfeel
  • Strong Hard-Soft Combination, Durable and Reliable
  • Long Mold Life, Suitable for Mass Production
  • Multi-Color and Multi-Material Overmolding Available
FAQ:
  • Q1: What is the accuracy of the overmolding mold?
    ±0.02mm
  • Q2: Do you support overmolding with different colors?
    Yes, we can achieve two- or multi-color solutions.
  • Q3: What is the typical mold lifespan?
    600,000–1.2 million mold cycles.
  • Q4: Are overmolded products prone to cracking?
    No, the molding process ensures stability.
  • Q5: Do you provide trial molds?
    Yes, we do, to ensure customer satisfaction and continued production.
Customized Services:

We offer comprehensive customization options, including mold cavity count, overmolding material, cooling design, and automation interfaces.
