Customizable 2K Injection Mold High Precision Dual Shot Injection Molding
Customizable 2K Injection Mold High Precision Dual Shot Injection Molding
Specifications
Brand Name :
MID MOULD
Place of Origin :
Dongguan, China
MOQ :
1 set
Payment Terms :
50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment
Delivery Time :
25–45 working days (longer for complex tools)
Certification :
ISO9001,FDA,ISO13485
Price :
USD $3,000–$50,000 per set (depending on complexity)
Packaging Details :
Wooden case + anti-rust oil + protective film + packing list
Supply Ability :
20–35 sets per month, depending on structure
Product :
2K Injection Mold
Shaping mode :
Plastic Injection Mould,Plastic injection molding,Compression Mould
Material :
STEEL,ps,PP,Steel and metal,aluminum
Mould life :
250000-300000shots,200~1 M available,300,000shots,000 times
Runner :
Hot Runner\ Cold Runner,cold/hot
Cavity :
Multi Cavity,as per client's requirement
Product material :
Plastic,Steel,PP,ABS,PS
Mold material :
NAK80,H13,50#,P20,45#
Design software :
CAD,CAD/ProE/UG/SOLIDWORKS,CAD UG Moldflow,Solidworks,PROE
Mould material :
P20/718/738/NAK80/S136,P20/718/2738/H13/S136/NAK80,718,SKD61 etc,H13
Application :
Home Appliance,Industrial,Automotive,various range,Machine
Product name :
Plastic Injection Mould,injection machine mold,Shanghai Factory Cheap Plastic Component Injection Mold,High quality virgin raw material custom plastic injection mold product,Gear parts
Mould base :
non-Standard plastic injection mould,World standard,European standard,LKM.HASCO,HASCO standard
Surface treatment :
sandblasted,Texture,anodizing black,clear painting,Polishing
Size :
as samples/drawings,customized accepted,Customized Size
Mold runner :
Hot&Cold runner you can choose,Hot runner and code runner
Mold life :
000 to 1,500000 shots,000 shots,100000-1000000,50
Plastic material :
Peek,ABS/PP/PS/PE/PVC/PA6/PA66..et,MC Nylon,Derlin,UHMW-PE
Description
Product Process

2K injection molds complete two injections in a single mold run, allowing for the combination of different materials or colors. This process eliminates the need for adhesives and post-processing, resulting in a more durable and durable product.

Process Flow
  1. Mold Structure Design and Two-Color Parting
  2. Mold Flow Analysis and Melt Filling Simulation
  3. CNC and Spark EDM Precision Machining
  4. Assembly of Rotating Structure and Cooling System
  5. Test Molds for Bonding and Accuracy
Product Specifications
Item Parameter Description
Mold Type2K Injection Mold
Mold MaterialH13 S136 NAK80
Number of Cavities1–8
Mold Life650,000–1.2 Million Molds
Surface TreatmentPolishing, Sandblasting, Chrome Plating
Applicable MaterialsABS PC PP + TPE TPU
Molding MethodRotary Mold with Slide Interchange
Product Accuracy±0.018mm
Cooling SystemMulti-Circuit Parallel Cooling
Product Cycle60–95 Days
Product Advantages
  • Secure Dual-Material Bond, No Adhesive Required
  • Beautiful Appearance and Strong Functionality
  • Long Mold Life and Controllable Costs
  • Suitable for High-Volume Continuous Production
FAQ
  • Q1: Can the mold support more than two colors?

    A1: Yes, it can be upgraded to a multi-color mold.

  • Q2: What is the production cycle?

    A2: Typically 60–95 days.

  • Q3: What is the mold accuracy?

    A3: ±0.018mm.

  • Q4: Is the mold easy to maintain?

    A4: Yes, we use a modular design.

  • Q5: Do you offer customization options?

    A5: Yes, we can customize according to customer needs.

Personalized Customization

We support a variety of customization options, including two-color layout, number of mold cavities, material combinations, and surface effects.
