PPR Strainer Valve PN25 Compact Y-Shape Filter Valve 20–32mm for Water Systems
PPR Strainer Valve PN25 Compact Y-Shape Filter Valve 20–32mm for Water Systems
PPR Strainer Valve PN25 Compact Y-Shape Filter Valve 20–32mm for Water Systems
PPR Strainer Valve PN25 Compact Y-Shape Filter Valve 20–32mm for Water Systems
PPR Strainer Valve PN25 Compact Y-Shape Filter Valve 20–32mm for Water Systems
PPR Strainer Valve PN25 Compact Y-Shape Filter Valve 20–32mm for Water Systems
PPR Strainer Valve PN25 Compact Y-Shape Filter Valve 20–32mm for Water Systems
PPR Strainer Valve PN25 Compact Y-Shape Filter Valve 20–32mm for Water Systems
PPR Strainer Valve PN25 Compact Y-Shape Filter Valve 20–32mm for Water Systems
PPR Strainer Valve PN25 Compact Y-Shape Filter Valve 20–32mm for Water Systems
Specifications
Brand Name :
DSTHERM/OEM/ODM
Model Number :
20-32mm
Certification :
ISO 9001
Place of Origin :
ZHEJIANG,CHINA
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C,T/T
Delivery Time :
around 30days
Packaging Details :
CUSTOMIZED/STANDARD
Product Name :
PPR Y-Type Filter Valve
Size :
20-32mm
Nominal Pressure :
PN25
Connection Type :
Heat fusion welding
Material :
PPR Body
Feature :
Y‑shape structure, full flow, low pressure drop
Applicable Temperature :
-20°C to 110°C
Electrical Conductivity :
Insulator (no galvanic corrosion)
Description

Description

Product Name PPR Y-Type Filter Valve
Size 20-32MM
Material Body: PPR; Screen: Stainless Steel 304
Nominal Pressure PN25
Applicable Media Water
Applicable Temperature -20°C to 110°C
Connection Type Heat fusion welding
Design Features Y‑shape structure, full flow, low pressure drop



Product Features


  1. Material – Valve body made of PPR, filter screen made of stainless steel 304.
  2. Pressure rating – PN25– higher than common brass filter valve.
  3. Size range – 20-32mm, cutomizable.
  4. Temperature range – -20°C to 110°C, suitable for both cold and hot water.
  5. Connection – Fusion socket welding (heat fusion) – no leakage.
  6. Hygienic – Non‑toxic, odourless, meets drinking water standards (GB/T 17219).
  7. Corrosion resistance – Excellent resistance to scale, rust, and most chemicals.
  8. Low flow resistance – Y‑shape design with smooth inner wall.
  9. Easy maintenance – Removable screen accessed via bottom cap.




Differences – PPR vs. Brass Y-Type Filter Valve


Aspect PPR Filter Valve Brass Filter Valve
Body Material PPR (Polypropylene) Brass (HPb59‑1/CW617N)
Pressure Rating PN25 PN16 typical
Temperature Range -20°C ~ 110°C -20°C ~ 120°C
Corrosion Resistance Excellent (immune to rust & scale) Good (may dezincify in aggressive water)
Hygienic / Drinking Water Yes, fully compliant Requires lead‑free brass for potable water
Connection Method Heat fusion welding (leak‑free) Threaded (BSPT / NPT) – needs sealant
Installation Requires special fusion tool Simple wrench tightening
UV Resistance Poor (must be installed indoors or protected) Excellent (suitable for outdoor use)
Mechanical Strength Good but less impact‑resistant High, withstands vibration & external forces
Weight Light Heavy
Cost Lower Higher
Electrical Conductivity Insulator (no galvanic corrosion) Conductor (may cause galvanic issues)




Applications


  • Domestic water supply.
  • Underfloor heating systems.
  • Hot water recirculation circuits.
  • Drinking water lines.
  • Small irrigation systems.
  • Industrial cooling water.


Our advantages


1). Over 20 Years' Experience in production

2). Accept OEM Order

3). ISO9001 approved

4). We use All New raw material in products

5). Sufficient products with complete specifications for your choice


We Will Be Your Better Choice!
