High speed SHR-5L/10L/25L/50L Explosion-proof Lithium Battery Laboratory Mixer

Specifications

Brand Name :

BEISU

Model Number :

SHR-BS-5

Certification :

Place of Origin :

China

MOQ :

1 Set

Price :

USD3000

Payment Terms :

L/C, T/T,

Supply Ability :

150 Sets per year

Delivery Time :

25 working days

Packaging Details :

Plastic film packing and pallet fixed on the machine bottom

Application :

UPVC/CPVC/OPVC/PE/PP/MASTERBATCH/CORBON

Model :

SHR-5L Plastic Mixer Machine

Heating mixermotor power :

2.2Kw/3Kw

Inverter brand :

Delta

Temperature control brand :

OMRON

Paddle mode :

2 Pcs

Discharge material :

S.S304

Speed :

1440rpm

Capacity :

10Kg/h

Description

Designed specifically for lithium battery R&D and pilot testing, the Lithium Battery Laboratory Mixer is a professional device that integrates efficient mixing, vacuum degassing, and precise temperature control. It can precisely process a variety of lithium battery-related materials, such as positive and negative electrode materials, conductive agents, and binders, ensuring high-quality mixing in a laboratory environment and providing a solid foundation for subsequent battery performance testing and optimization.

High speed SHR-5L/10L/25L/50L Explosion-proof Lithium Battery Laboratory Mixer

Features of the Lithium Battery Laboratory Mixer:
A1: High-Speed Shear Mixing: Operating at speeds of 3000-6000 rpm, specially designed impellers (such as turbine and paddle types) generate intense shear and convection, rapidly breaking up powder agglomerates and uniformly blending powders of varying particle sizes and densities in a short period of time, with a mixing uniformity deviation of <3%.

A2: Precise Speed and Time Control: Supporting multi-level speed adjustment, the stirring speed and mixing time can be set based on powder characteristics (such as flowability and particle size), preventing powder breakage or insufficient mixing due to over-mixing. Dust-proof design: Equipped with a sealed mixing chamber and a negative pressure dust collection device, this reduces powder dust during the feeding and mixing process, protecting operator health while also preventing material loss and cross-contamination.

A3:Material Adapted to Powders: Material contact parts are constructed of SUS316L stainless steel with a wear-resistant treatment to withstand powder friction while preventing the introduction of metallic impurities and ensuring powder purity.

Technical date:

Model	Total volume	Available capacity	Motor power	Shaft speed	Heating method
SHR-5A	5L	3L	1.1Kw	1400rpm	Self friction/electric
SHR-10A	10L	7L	3Kw	2000rpm
SHR-25A	25L	20L	5.5Kw	1440rpm
SHR-50A	50L	35L	7/11Kw	750/1500rpm
SHR-100A	100L	75L	14/22Kw	650/1300rpm
SHR-200A	200L	150L	30/42Kw	475/950rpm
SHR-300A	300L	225L	40/55Kw	475/950rpm
SHR-500A	500L	375L	47/67Kw	430/860rpm
SHR-800A	800L	600L	60/90Kw	370/740rpm
SHR-1000A	1000L	750L	83/110Kw	350/700rpm

High speed SHR-5L/10L/25L/50L Explosion-proof Lithium Battery Laboratory Mixer

Zhangjiagang Beisu Machinery Co,Ltd is a certified manufacturer, exporter and supplier of

plastic PVC/PE/PP/PET/EVA/ABS processing machinery. Due to our constant commitment to

extrusion technology, we have emerged as a leading manufacturer of Plastic Extrusion

Machinery for PVC pipes Extrusion Line, HDPE pipes Extrusion Line, PVC compounding

Extruder, PPR Pipes Extrusion Line, PVC profiles Extrusion Line.

Especially High speed Plastic mixer, PVC compounding mixer, SPC mixer.WPC mixer,Plastic Granulating and Pelletizing Line,Plastic pvc pelletizing machine,Soft PVC shoes granulator, PVC compounding pelletizer and Plastic PVC pulverizer, PVC miller,SPC milling machine, WPC pulverizer, SPC pulverizer, PE pulverizer,LDPE pulverizer,PET pulverizer,ABS pulverizer,HDPE pulverizer,Plastic pulverizer, Plastic milling machine, Plastic miller machine,Plastic Crusher,PVC crusher,PE crusher,PP shredder, Plastic PVC Shredder etc for a wide range of extrusion processes.

1. Before shipment testing at factory, vedio record.
2. Vedio instruction for operation.
3. User manual and installation instruction, layout and drawings.
4. Lable&marks for disassemble parts, wiring&cables.

1.Reliable

Most popular design with years' verification.
Mature supply chain for raw materials with strict quality assurance.
International famous brands of key parts i.e. ABB invertor, Internationally renowned brand electronics, Internationally renowned brand motor, Mettler Toledo scale etc.

2. Economy

BEISU Stable technology commercialized in China.
High efficiency mixing performance.
Cost effective solutions.

Real time communication SNS group chat(WeChat preferred, Skype/WhatsApp) which includes buyer side and BEISU service team is created for technical assistance in the quickest manner. Scheduled video calls are also available. Just as the company vision 'Customer Oriented' says,BEISU always stands at customer's point to offer the optimum solution and help customer to maximize profit. BEISU has its own customer management system and spare parts management system which ensure quickest responds and enough regular easy-wearing parts whenever customer requests.
