Super Plc Rotary Blade 500kg/H Plastic Shredder Machine
Super Plc Rotary Blade 500kg/H Plastic Shredder Machine
Super Plc Rotary Blade 500kg/H Plastic Shredder Machine
Super Plc Rotary Blade 500kg/H Plastic Shredder Machine
Super Plc Rotary Blade 500kg/H Plastic Shredder Machine
Super Plc Rotary Blade 500kg/H Plastic Shredder Machine
Super Plc Rotary Blade 500kg/H Plastic Shredder Machine
Super Plc Rotary Blade 500kg/H Plastic Shredder Machine
Super Plc Rotary Blade 500kg/H Plastic Shredder Machine
Super Plc Rotary Blade 500kg/H Plastic Shredder Machine
Super Plc Rotary Blade 500kg/H Plastic Shredder Machine
Super Plc Rotary Blade 500kg/H Plastic Shredder Machine
Specifications
Place of Origin :
CN;JIA
Brand Name :
BEISU
Certification :
CE,ISO
Supply Ability :
200 Set/Sets per Year
Packaging Details :
Film packing or wood package as customer requirements
MOQ :
1 - 2 Sets
Price :
$22,000.00
Condition :
New
Machine Type :
Plastic Shredder
Max.Production Capacity (kg/h) :
3000
Production Capacity (kg/h) :
500 - 3000 kg/h
Use :
Waste Plastic Crusher
Shaft Design :
Single
Voltage :
220V/380V/415V/440V
Dimension(L*W*H) :
4000mm*2500mm*2200mm
Power (kW) :
55
Weight (T) :
4
Applicable Industries :
Manufacturing Plant
Key Selling Points :
Automatic
Raw material :
PE pipes/PVC pipes/Wood/Pallets/Plastic containers
Motor power :
55Kw
Material blade :
SKD-11 or Stainless steel or Tungsten steel
Blade type :
V
Rotary blade :
68
Fixed blade :
2~4PCS
Bearing brand :
NSK or SKF or Wafandian
OIL filling system :
Oil pump
Contactor brand :
Internationally renowned brand
PLC :
Internationally renowned brand
Port :
SHANGHAI or NINGBO PORT
Description
Super Plc Rotary Blade 500kg/H Plastic Shredder Machine

Applications of Single shaft shredder machine:

- plastic lump and plastic block, like PP, PE, PET, PC, ABS, Nylon.

-Plastic pipes

-PP/PE film,Woven bags

- Living garbage,

- Medical waste

-Electronic Waste

-Copper Cable,Aluminum Cable with steel

- Aluminum cans

-Wood,Pallet,tree root,solid wood etc

The BS shredders have been designed for the most demanding and high throughput applications in recycling industries,Clients could select the corresponding models according to the material size and quantity. Well as for the different special needs, providing a special knife rotor, for shredded material as film, woven bags or nylon, ABS and PC.

Features of Single shaft shredder machine:

• Teeth are DC53 steel. Stator knives are D2 steel.

• The main electronic controls are a combination of Internationally renowned brand and Schneider.

• Microcomputer technology incorporating rotator speed variations with start, stop and reverse features.

• Automatic reverse sensors to protect the machine against over loading and jamming.

• Engineered using split bearing block technology so the blades can be changed quickly and efficiently.

• Specifically designed rotor to be extremely wear resistant.

• Rotor teeth can be rotated 4 times before they need changing, lowering running costs and reducing down time.

• Extremely versatile machine able to process a number of different materials

• Machinery protection, accord with the European CE standard.

Super Plc Rotary Blade 500kg/H Plastic Shredder Machine
Super Plc Rotary Blade 500kg/H Plastic Shredder Machine
Super Plc Rotary Blade 500kg/H Plastic Shredder Machine
Super Plc Rotary Blade 500kg/H Plastic Shredder Machine
Super Plc Rotary Blade 500kg/H Plastic Shredder Machine
Super Plc Rotary Blade 500kg/H Plastic Shredder Machine
Super Plc Rotary Blade 500kg/H Plastic Shredder Machine
Super Plc Rotary Blade 500kg/H Plastic Shredder Machine
Super Plc Rotary Blade 500kg/H Plastic Shredder Machine
Super Plc Rotary Blade 500kg/H Plastic Shredder Machine
Model Motor power (KW) Power of propeller (KW) QTY. of moving blades QTY. of fixed blades

Rotation speed

(r/min)

Weight

(kg)
BS-2250 15 2.2 26 4 83 1400
BS-2260 18.5 2.2 30 4 83 1550
BS-4060 30 3.75 34 4 83 3000
BS-4080 37 3.75 46 4 83 3600
BS-40100 45 3.75 58 4 83 4000
BS-40120 55 5.5 70 6 83 5000
BS-40150 75 5.5 88 6 83 6200
BS-48120 90 5.5 102+33 3 83 7000
BS-48150 90 5.5 102+33 3 83 8500
BS-48200 55+55 5.5 177 4 83 10500
BS-48250 55+55 5.5 102+33 4 83 12800
