Multiple Disc Brakes Electric Torque Hub for Wheel Drives and Planetary Gear Units
Multiple Disc Brakes Electric Torque Hub for Wheel Drives and Planetary Gear Units
Multiple Disc Brakes Electric Torque Hub for Wheel Drives and Planetary Gear Units
Multiple Disc Brakes Electric Torque Hub for Wheel Drives and Planetary Gear Units
Multiple Disc Brakes Electric Torque Hub for Wheel Drives and Planetary Gear Units
Multiple Disc Brakes Electric Torque Hub for Wheel Drives and Planetary Gear Units
Multiple Disc Brakes Electric Torque Hub for Wheel Drives and Planetary Gear Units
Multiple Disc Brakes Electric Torque Hub for Wheel Drives and Planetary Gear Units
Multiple Disc Brakes Electric Torque Hub for Wheel Drives and Planetary Gear Units
Multiple Disc Brakes Electric Torque Hub for Wheel Drives and Planetary Gear Units
Multiple Disc Brakes Electric Torque Hub for Wheel Drives and Planetary Gear Units
Multiple Disc Brakes Electric Torque Hub for Wheel Drives and Planetary Gear Units
Specifications
Model NO. :
HYTE001
Output Torque :
Higher Output Torque
Custom :
Customized Design
Brand :
Elite/OEM
Ratio :
Different Ratios
Brakes :
Multiple Disc Brakes
Load Capacity :
Higher Load Capacity
Assembly :
Easy Assembly
Transport Package :
Wooden Boxes
Trademark :
Elite
Origin :
China
HS Code :
8483402090
Supply Ability :
90000 Pieces/Year
Application :
Motor, Motorcycle, Machinery, Agricultural Machinery
Function :
Change Drive Torque, Speed Changing, Speed Reduction
Hardness :
Hardened Tooth Surface
Step :
Three-Step
Type :
Planetary Gear Box
Warranty :
18 Months
Customization :
Available | Customized Request
Place of Origin :
China
Certification :
ISO 9001, ISO 14001, IATF16949
Packaging Details :
Wooden Boxes
Delivery Time :
Peak Season Lead Time: one month, Off Season Lead Time: within 15 workdays
Payment Terms :
LC, T/T, D/P, PayPal
MOQ :
5
Description

Elite HFTE planetary drives incorporate an integrated, maintenance-free electric motor and offer significant benefits, including compact dimensions, low noise and high efficiency. HFTE Series drives are designed for use with all kinds of aerial platforms and other types of mobile machinery, for indoor and outdoor use. This advanced powertrain solution uses a two- or three-stage gearbox offering reduction ratios of up to 1:153 to satisfy the widest possible range of needs. The gearbox is coupled with a low-voltage induction motor (BT Series), specially developed for traction power and control applications.
Key features
Two- or three-stage planetary drive with reduction ratios of up to 1:153
Optimized gear design for maximum efficiency and minimum noise
Integrated, low voltage, 3 phase induction motor with inverter
Integrated, high accuracy, KTY temperature sensor
High resolution, Hall effect speed sensor
Multiple Disc Brakes Electric Torque Hub for Wheel Drives and Planetary Gear Units

Multiple Disc Brakes Electric Torque Hub for Wheel Drives and Planetary Gear Units
HFT003 3000 6,8,32 4000 √ √ 1-1.3 35-55 Bonfiglioli601R1
Bonfiglioli
702C
RR RRWD200
RR RRWD270
RR RRWD300
RR RRTD300
RR RRTD100
HFT005 5000 5-55 4000 √ √ 1-1.3 50 BrevIni CTD2050
RR RML793
Bonfiglioli 603W
Bonfiglioli 703C
Omni VB04
RR RRWD500D
HFT007 7000 11-57 4000 √ √ 1.1 50 PMP PMR 680
Rexroth 8105E
RRWD600D
Brevini 402
Omni VB07
Fairfield 7HP
Bonfiglioli 603W
AuburnGear Model 70CD
HFT010 10000 25-63 4000 √ √ 1.5 56-63 O&K F10
Brevini CTD2010
Bonfiglioli 605W
Bonfiglioli 705C
RR RRWD800D
RR RRT800D
RR RRTD1000D
Rexroth 8110E
PMP PMR 780
Comer PGR-802T
HFT011 13000 26-59 4000 √ 2 80 Fairfield 11HP
Omni VB11
Rexroth 8120E
0&K F13
PMP PMR 1100
PMP PMR 1200
AuburnGear Model 110CD
HFT017 17000 26-141 4000
 √ 2.5 90 Rexroth GFT17
Bonfiglioli 706C
Brevini CTU3150
Brevini 703
RR RRWD1700D
Omni VB18
0&K F20
RR RRTD1700T
Fairfield CW18
Fairfield CW12
Comer PGR-1702/3T
Comer PGR-1702/3W
AuburnGear Model 161CD
AuburnGear Model 160CD


Our Advantages


Multiple Disc Brakes Electric Torque Hub for Wheel Drives and Planetary Gear Units
Product Description

Multiple Disc Brakes Electric Torque Hub for Wheel Drives and Planetary Gear Units

Multiple Disc Brakes Electric Torque Hub for Wheel Drives and Planetary Gear Units

Multiple Disc Brakes Electric Torque Hub for Wheel Drives and Planetary Gear UnitsMultiple Disc Brakes Electric Torque Hub for Wheel Drives and Planetary Gear Units
Multiple Disc Brakes Electric Torque Hub for Wheel Drives and Planetary Gear UnitsMultiple Disc Brakes Electric Torque Hub for Wheel Drives and Planetary Gear Units

Multiple Disc Brakes Electric Torque Hub for Wheel Drives and Planetary Gear Units
Multiple Disc Brakes Electric Torque Hub for Wheel Drives and Planetary Gear UnitsIn conclusion, ELITE Hydraulic offers quality, value, and professional power transmission solutions that cater to a wide variety of industries. With their expertise, experience, and commitment to customer satisfaction, you can be sure that you're in safe hands when working with them. Whether you need gearbox, electrical drive, or other hydraulic transmission solutions, you can trust ELITE Hydraulic to provide you with the best possible solutions. Contact them today to learn more about their power transmission products and services.
