Specifications
Brand Name :
OUSTER
Model Number :
A2FO
Place of Origin :
CHINA
MOQ :
1
Price :
258-618
Payment Terms :
T/T,Western Union,MoneyGram
Supply Ability :
500pcs/month
Delivery Time :
2-7days
Packaging Details :
paper box/wooden box
Color :
metal color
Warranty :
one year
Delivery time :
In stock /based on warehouse situation
Packge :
paper box/wooden box
Sizes :
standard design
Material :
steel iron and copper
Shipping way :
By courier/by air/by sea
Ship cost :
not include
Painting :
non/blue/black/grey/as your like
Application Fields :
Construction machinery
Description
A2FO Series Hydraulic Pump Fixed Displacement 400 Bar for Presses and forming machinery
Product Description:
The Rexroth A2FO series represents high-performance fixed displacement axial piston pumps designed for demanding open and closed circuit applications. With a compact design and exceptional power density, these pumps deliver reliable operation in industrial and mobile machinery.
---
Key Features & Benefits:
· Fixed Displacement Design: Provides consistent flow output for applications requiring precise hydraulic power transfer
· High Pressure Capability: Operates at pressures up to 400 bar (5,800 psi)
· Multiple Size Options: Displacement ranges from 10 cm³/rev to 500 cm³/rev
· High Efficiency: Optimized hydraulics minimize energy loss through reduced internal leakage
· Robust Construction: Hardened steel components and precision manufacturing ensure long service life
· Multiple Mounting Options: Standard SAE and ISO mounting configurations available
---
Technical Specifications:
· Pressure Rating:
· Maximum Operating Pressure: 400 bar
· Peak Pressure: 450 bar
· Speed Range: Up to 3,000 rpm (depending on model)
· Fluid Compatibility: Mineral oils, synthetic fluids, and environmentally acceptable fluids
· Temperature Range: -40°C to +90°C (-40°F to +194°F)
· Noise Level: <78 dB(A) at 1500 rpm
---
Applications:
· Industrial hydraulic power units
· Mobile machinery hydraulic systems
· Machine tools and production equipment
· Presses and forming machinery
· Marine and offshore equipment
· Test stand and simulation systems

FAQ


Q:accept sample order or provide free sample ?

A:yes,we can provide sample ,when you order more pcs in your next order ,we can refund sample fee to you.


Q:what's package ?

A:our packing is neutral packing ,paper box or wooden box.



Q:what payment you can accept ?

A:/TT/western union/moneygram/alipay/ online payment


Q: have warranty ?

A: our all product have warranty half /one year,based on different products


Q: tested before shipping ?

A: yes ,tested each before shipping


Q:after payment when you can shipping the goods

A: after you pay ,about 1-3days can shipping your goods if have stock.


Q:how to confirm if the goods is what we want?

A:we can send you drawing and pictures to check to avoid mistake


R900030678 A2FO 45/61L-PPB05
R900222323 A2FO 45/61L-PZB050
R902024832 A2FO45/61L-PAB05
R902161281 A2FO45/61L-PAB05
R902021547 A2FO45/61L-PPB05
R902243315 A2FO45/61L-PPB05
R902193320 A2FO45/61L-PPB05-S
R902198111 A2FO45/61L-PPB05-S
R902204620 A2FO45/61L-PPB05-S
R902050853 A2FO45/61L-PSB05-S
R902021531 A2FO45/61L-PZB05
R992001364 A2FO45/61L-PZB05
R902193314 A2FO45/61L-PZB05-S
R902038666 A2FO45/61L-VAB05
R902038700 A2FO45/61L-VPB05
R902222227 A2FO45/61L-VPB05
R902156034 A2FO45/61L-VPB05
R902030637 A2FO45/61L-VPB05-S
R902024696 A2FO45/61L-VZB05
R902222389 A2FO45/61L-VZB05
R902208796 A2FO45/61L-VZB05
R902063557 A2FO45/61L-VZB05-S
R902193751 A2FO45/61L-VZB05-S
R902182462 A2FO45/61L-VZB05-S
R902132084 A2FO45/61L-VZB05-S
R909422313 A2FO45/61R-PAB05
R902197514 A2FO45/61R-PAB05-S
R909603799 A2FO45/61R-PPB040-S
R902208593 A2FO45/61R-PPB040-S
R909411590 A2FO45/61R-PPB05
R902193387 A2FO45/61R-PPB05
R902201847 A2FO45/61R-PPB05-S
R902193858 A2FO45/61R-PPB05-S
R902193578 A2FO45/61R-PPB05-S
R902198020 A2FO45/61R-PPB05-S
R902050851 A2FO45/61R-PSB05-S
R992001514 A2FO45/61R-PZB05
R909411585 A2FO45/61R-PZB05
R902197693 A2FO45/61R-PZB05
R902193496 A2FO45/61R-PZB05-S
R902198080 A2FO45/61R-PZB05-S
R909610835 A2FO45/61R-VAB05
R902261464 A2FO45/61R-VPB040-Y
R909433630 A2FO45/61R-VPB05
R902193574 A2FO45/61R-VPB05
R902198278 A2FO45/61R-VPB05
R902193700 A2FO45/61R-VPB05
R902193585 A2FO45/61R-VPB05
R902198344 A2FO45/61R-VPB05
R902223193 A2FO45/61R-VPB05
R902016827 A2FO45/61R-VPB05-S
R902193576 A2FO45/61R-VPB05-S
R909448571 A2FO45/61R-VZB05
R902247469 A2FO45/61R-VZB05
R902198079 A2FO45/61R-VZB05
R902198194 A2FO45/61R-VZB05
R909422754 A2FO45/61R-VZB05-S
R902250771 A2FO45/61R-VZB05-Y
R902045487 AA2FO45/61L-NPD55
R902024991 AA2FO45/61L-NSD55
R902075294 AA2FO45/61L-VPD55
R902161106 AA2FO45/61L-VPD55
R902160973 AA2FO45/61L-VSD05-S
R902237422 AA2FO45/61L-VSD05-Y
R902193248 AA2FO45/61L-VSD55
R909418838 AA2FO45/61R-NPD55
R902028612 AA2FO45/61R-NSD05-S
R902028746 AA2FO45/61R-NSD05-S
R909423036 AA2FO45/61R-NSD55
R902014064 AA2FO45/61R-VPD55
R902193874 AA2FO45/61R-VPD55
R902161484 AA2FO45/61R-VPD55
R902000362 AA2FO45/61R-VSD55
R902161001 AA2FO45/61R-VSD55
R902158785 AA2FO45/61R-VSD55
R902161188 AA2FO45/61R-VSD55-S
