Specifications
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Core Components :
PLC, Engine, Bearing, Gearbox, motor, Pump
Type :
Pipe Mill
Pipe Material :
Stainless Steel,Carbon Steel,Galvanize,Iron,Steel
Application :
Energy Supply Pipe
Production Capacity :
90t/h
Place of Origin :
Jiangsu, China
Brand Name :
Nanyang
Voltage :
220V/380V/415V/440V
Power(w) :
820000
Dimension(L*W*H) :
24m*3.1m*1.7m
Weight :
36000 kg
Warranty :
one year
Key Selling Points :
Long Service Life
Diameter of welded tube :
16~50.8mm
Wall Thickness of welded tube :
0.5~2.5mm
Milling speed :
30~110M/min
Main motor power :
132KW
High frequency power :
200KW
Annual output :
32900t
Pipe shape :
Round / Square / Rectangle / Oval
Welding type :
Argon Welding
coil Material :
Stainless steel / Carbon steel / Iron / Aluminum / Copper
Color :
Bule Green Purpie
Applicable Industries :
Building Material Shops, Manufacturing Plant, Construction works , Energy & Mining
Showroom Location :
None
Warranty of core components :
1 Year
Condition :
New
Marketing Type :
Hot Product 2021
Packaging Details :
Sea worthy packing
Port :
Shanghai
Supply Ability :
200 Set/Sets per Year pipe mill line
Price :
CN¥144,092.00/sets >=1 sets
Description
Products Description
30-110M/min Milling Speed Pipe Mill for High Frequency Circular Erw Iron Welding Pipe Making Machine
30-110M/min Milling Speed Pipe Mill for High Frequency Circular Erw Iron Welding Pipe Making Machine
30-110M/min Milling Speed Pipe Mill for High Frequency Circular Erw Iron Welding Pipe Making Machine

Model

Welded pipe diameter

Welded pipe wall thickness

Welding speed

Main motor power

High frequency power
ZG16
Φ8～Φ25mm
δ0.25～1.0mm
30～120M/min
37KW
100KW
ZG25
Φ8～Φ32mm
δ0.3～1.3mm
40～120M/min
45KW
100KW
ZG32
Φ13～Φ40mm
δ0.4～2.0mm
30～110M/min
110KW
150KW
ZG45
Φ16～Φ50.8mm
δ0.5～2.5mm
30～110M/min
132KW
200KW
ZG50
Φ19～Φ63.5mm
δ0.6～3.0mm
30～100M/min
160KW
200KW
ZG60
Φ19～Φ63.5mm
δ0.7～3.5mm
30～100M/min
200KW
250KW
ZG76
Φ25～Φ90mm
δ0.9～4.0mm
20～80M/min
200KW
300KW
ZG90
Φ38～Φ127mm
δ1.2～4.5mm
20～70M/min
132KW×2
400KW
ZG115
Φ48～Φ127mm
δ1.4～5.0mm
20～60M/min
160KW×2
400KW
ZG165
Φ50.8～Φ165mm
δ1.8～6.0mm
15～50M/min
200KW×2
500KW
ZG219
Φ89～Φ219mm
δ2.0～8.0mm
12～40M/min
250KW×2
600KW
ZG273
Φ114～Φ273mm
δ2.5 ～10.0mm
10～30M/min
132KW×2, 160KW×2
800KW
ZG325
Φ168～Φ325mm
δ3.0 ～12.0mm
10～30M/min
160KW×2, 200KW×2
1000KW
ZG530
Φ219～Φ530mm
δ4.0 ～16.0mm
10～30M/min
75KW×5, 160KW×8
1500KW
