3m/Min HDPE Pipe Extrusion Machine Single Screw Fast Speed
3m/Min HDPE Pipe Extrusion Machine Single Screw Fast Speed
3m/Min HDPE Pipe Extrusion Machine Single Screw Fast Speed
3m/Min HDPE Pipe Extrusion Machine Single Screw Fast Speed
Specifications
Brand Name :
SD Huasu Brand
Model Number :
600H
Certification :
CE, ISO9001:2008, UL, QS, GMP
Place of Origin :
CHINA
MOQ :
1 SET
Payment Terms :
T/T
Supply Ability :
50 sets/month
Delivery Time :
30 working days
Packaging Details :
standard package or as required
Name :
HDPE Pipe Extrusion Machine
Screw design :
Single-screw
Screw Material :
38CrMoALA
Brand name :
Shandong Huasu
Showroom Location :
Russia, Korea, Japan etc.
Voltage :
380V or as required
SJ-120/33 :
250KW
SJ-90/33 :
132KW
Description

3m/Min Hdpe Pipe Extrusion Machine Single Screw Fast Speed

This HDPE Pipe Extrusion Machine can be equipped with single screw extruder or parallel twin screw extruder. The haul off machine has three-way, four-way, six-way type. The cutting machine has blade saw cutting and planetary cutting method. Huade also supply all kinds of moulds.

Extruder Motor Max. Output Note
SJ120/33 250kw 800kg/h
SJ90/33 132kw 450kg/h
No. Name & Model Quantity
01 Single screw extruder SJ-120/33 1 set
02 Single screw extruder SJ-90/33 1 set
03 Molds OD 200mm die head water sleeve mould block 1 set
OD 250mm die head water sleeve mould block 1 set
OD 500mm die head water sleeve mould block 1 set
OD 630mm die head water sleeve mould block 1 set
04 Forming machine SBCJ-600 1 set
05 Water cooling tank SBSC-600 with haul-off machine 1 set
06 Planetary chip free cutting machine SBQG-600 1 set
07 Unloading bracket SBXL-600 1 set
08 PLC control system 1 set
09 Spare parts 1 set

For normal speed line, please contact Ellen Liu for more details.

3m/Min HDPE Pipe Extrusion Machine Single Screw Fast Speed

3m/Min HDPE Pipe Extrusion Machine Single Screw Fast Speed

3m/Min HDPE Pipe Extrusion Machine Single Screw Fast Speed
