Sealing Performance Bevel Gear Wedge Gate Valve for Normal and High Temperature Environments
Sealing Performance Bevel Gear Wedge Gate Valve for Normal and High Temperature Environments
Sealing Performance Bevel Gear Wedge Gate Valve for Normal and High Temperature Environments
Sealing Performance Bevel Gear Wedge Gate Valve for Normal and High Temperature Environments
Specifications
Brand Name :
JGPV
Place of Origin :
China
MOQ :
1set
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
100pcs per month
Delivery Time :
14 days
Packaging Details :
Plywood box safety packing
Application: :
General
Certificate: :
ISO9001, ISO14001
Medium Type: :
Water, steam and oil etc.
Function： :
Condensate drain
Connection: :
Screw connection
Mounting Type: :
Direct Mount
Standard Or Non-Standard: :
Standard
Flow way: :
Two way
Actuation: :
Manual, Electric, Pneumatic,Automatic
Sealing Performance: :
Sealing
Working Temperature: :
Normal Temperature And High Temperature
Pressure Application: :
Normal Pressure
Quality Warranty: :
18 Months
Description

Highlight: Bevel gear wedge gate valve


Product introduction:


Gate valve refers to a valve in which the closing element (gate) moves vertically along the centerline of the passage. Gate valves are mainly used for cutting off in pipelines. Gate valve is a widely used type of valve. Gate valves can only be used for fully open and fully closed blocking in pipelines, and cannot be used for adjustment or throttling.


Product technical parameters:


Nominal Diameter DN (mm)

15~200

Nominal Pressure PN (MPa)

1.6

Test Pressure (MPa)

Strength (water)

2.4

Enclose (Water)

1.76

Main Components

Body

WCB/CF8/CF8M

Valve ball

Stainless steel/Carbon steel

Seat

PTFE

Packing

Soft graphite

Shaft

2Cr13

Handle

Ductile iron

Working temperature

≤150℃

Medium suitable

Water, oil, steam


Product features:


1. Compact structure, reasonable design, good valve rigidity, smooth flow channel, and small flow coefficient.

2. The sealing surface is made of stainless steel and cemented carbide, ensuring a long service life.

3. Flexible graphite packing is adopted, featuring reliable sealing and easy, flexible operation.

4. The driving modes include manual, pneumatic, electric, and gear transmission.

5. The structural forms are elastic wedge single gate, rigid wedge single gate, and double gate types.


Our Advantages:


Sealing Performance Bevel Gear Wedge Gate Valve for Normal and High Temperature Environments

Sealing Performance Bevel Gear Wedge Gate Valve for Normal and High Temperature Environments

Sealing Performance Bevel Gear Wedge Gate Valve for Normal and High Temperature Environments

Sealing Performance Bevel Gear Wedge Gate Valve for Normal and High Temperature Environments

Sealing Performance Bevel Gear Wedge Gate Valve for Normal and High Temperature Environments
