Automatic Actuation Electric Butterfly Valve Ideal For Normal Pressure Applications
Automatic Actuation Electric Butterfly Valve Ideal For Normal Pressure Applications
Specifications
Place of Origin :
China
MOQ :
1set
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
100pcs per month
Delivery Time :
14 days
Packaging Details :
Plywood box safety packing
Application: :
General
Medium Type: :
Water, steam and oil etc.
Mounting Type: :
Direct Mount
Standard Or Non-Standard: :
Standard
Flow way: :
Two way
Actuation: :
Manual, Electric, Pneumatic,Automatic
Sealing Performance: :
Sealing
Working Temperature: :
Normal Temperature And High Temperature
Pressure Application: :
Normal Pressure
Quality Warranty: :
18 Months
Description

Highlight: Electric butterfly valve


Product introduction:


The Electric Stainless Steel Butterfly Valve D971F (Electric Stainless Steel Wafer Butterfly Valve/Electric Stainless Steel PTFE Sealed Butterfly Valve/Electric Stainless Steel Rubber Sealed Butterfly Valve/Electric Stainless Steel Wafer-Type Butterfly Valve) features a compact design, lightweight construction, reliable performance, simple configuration, and high flow capacity. It is particularly suitable for applications involving viscous, particulate, or fibrous media. Widely used in industrial automation systems across various sectors including food processing, environmental protection, light industry, petroleum, paper manufacturing, chemical engineering, educational and research equipment, and power generation.


Product technical parameters:


Type number

D971F-16P

Nominal Diameter DN(mm)

50～1200

Nominal Pressure PN(MPa)

1.6

Control method

Electricity: On/off switch

Power supply

AC380V

Main parts

Valve body

Stainless steel 304 (CF8)

Disc

Stainless steel 304 (CF8)

Valve seat

PTFE

Axle

Stainless steel 304 (CF8)

Medium suitable:

Water, air, oil and nitric acid etc corrosive medium

Working temperature

150≤℃

Connection type

Wafer type


Product features:


  1. The electric stainless steel butterfly valve body requires only a small installation space, and its working principle is simple and reliable.
  2. The electric stainless steel butterfly valve has a high flow capacity, with minimal pressure loss through the valve.
  3. The electric stainless steel butterfly valve offers significant economic advantages, especially for larger-diameter models.
  4. The valve body is compatible with standard raised-face pipe flanges.
  5. Its nearly equal-percentage flow characteristic makes it suitable for both regulating and on-off control applications.
  6. The special valve seat seal is suitable for clean liquid and gas media.
