Water Medium Bellow Sealed SS Forged Globe Valve with General Application
Water Medium Bellow Sealed SS Forged Globe Valve with General Application
Specifications
Place of Origin :
China
MOQ :
1set
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
100pcs per month
Delivery Time :
14 days
Packaging Details :
Plywood box safety packing
Application: :
General
Medium Type: :
Water, steam and oil etc.
Mounting Type: :
Direct Mount
Standard Or Non-Standard: :
Standard
Flow way: :
Two way
Actuation: :
Manual, Electric, Pneumatic,Automatic
Sealing Performance: :
Sealing
Working Temperature: :
Normal Temperature And High Temperature
Pressure Application: :
Normal Pressure
Quality Warranty: :
18 Months
Description

Highlight: Bellow sealed SS forged globe valve


Product introduction:


The stem axis of the bellows globe valve WJ41W is perpendicular to the sealing surface of the valve seat. The opening or

closing stroke of the stem is relatively short, and it has a very reliable cutting action, making this valve suitable for cutting,

regulating, and throttling media. Bellows valves are high-quality products for creating a leak-free factory. The stainless steel

bellows globe valve has the properties of corrosion resistance, heat resistance, and low-temperature resistance. The selection

of stainless steel material enables this valve to be widely used in controlling general corrosive media and industrial and mining

conditions with high hygiene requirements, in addition to having the advantages of bellows globe valves made of ordinary

materials.


Product technical parameters:


Nominal Pressure PN(MPa)

1.0 - 4.0

Nominal Diameter DN(mm)

15～600

Test pressure (MPa)

Strength (water)

1.5 times of pressure nominal

Sealing (water)

1.1 times of pressure nominal

Sealing (Air)

0.6 times of pressure nominal

Sealing for bellows (water)

1.5 times of pressure nominal

Raw material

WCB, CF8, CF8M

Medium suitable:

Water, steam, oil mediums

Working temperature

-196℃～600℃

Connection type

Flange

Operational method

Hand-wheel, bevel gear, pneumatic and electric actuators


Product features:


1. Reasonable product structure, reliable sealing, excellent performance and beautiful appearance.

2. The sealing surface is surfacing welded with Co hard alloy, which has good corrosion resistance, friction resistance and

long service life.

3. The valve stem is quenched and tempered and surface nitrided, which has good corrosion resistance and friction resistance.

4. Double sealing performance.

5. The valve stem lifting position indication is more intuitive.

6. The part materials, flange and butt weld dimensions can be reasonably selected according to the actual working conditions

or user requirements to meet various engineering needs.
