Ductile Iron Diaphragm Type Adjustable Pressure Reducing and Stabilizing Valve for Fire Fighting Water Direction Adjustment
Ductile Iron Diaphragm Type Adjustable Pressure Reducing and Stabilizing Valve for Fire Fighting Water Direction Adjustment
Specifications
Brand Name :
JGPV
Model Number :
YX8741X-JGPV
Place of Origin :
CHINA
MOQ :
1 Set
Price :
USD75.9/Set - 269.9/Set
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
1000pcs per month
Delivery Time :
14 days
Packaging Details :
Plywood box safety packing
Standard or Non-standrd :
Standard
Application :
General
Product function :
Fire fighting water direction adjustment
Construction :
Diaphragm
Working temperature :
Normal temperature
Pressure application :
Nomal pressure
Power :
Hydraulic
Manufacturing craft :
Casting
Body material :
Ductile iron
Quality warranty :
18 months
Description
Diaphragm Type Adjustable Pressure Reducing Valve And Stabilizing Valve Ductile Iron
Product Overview

Ductile Iron Diaphragm Type Adjustable Pressure Reducing And Stabilizing Valve

Fire fighting valve products are control accessories on industrial and building pipelines. These valves are the most important controlled accessories, typically consisting of valve body, opening and closing mechanism, and valve cover. They feature simple structure and reliable sealing performance.

Most fire valves utilize clamp connections, simplifying the complex valve installation and pipeline connection process, making it fast and convenient. This represents a significant advancement in pipeline connection technology.

Technical Specifications
Parameter Specification
Nominal Diameter DN (mm) 65~200
Nominal Pressure PN (MPa) 1.6/2.5
Test Pressure (MPa) - Strength (water) 2.4/3.8
Test Pressure (MPa) - Enclose (Water) 1.8/2.8
Working Temperature 0~80℃
Suitable Medium Water
Product Features
  • High sensitivity, safety and reliability, easy debugging, and long service life
  • Stable pressure control with continuous pilot valve and main valve operation
  • Downstream pressure changes continuously and steadily with minimal influence from inlet pressure
  • Filter should be installed in front of the valve for easy discharge of pollutants
Application Benefits

The YX8741X diaphragm adjustable pressure reducing and stabilizing valve is used in parallel water supply systems for firefighting and domestic use. During fire emergencies, it automatically cuts off domestic water to ensure sufficient fire water supply. When fire water pressure decreases, the valve automatically opens to restore domestic water supply, eliminating the need for separate fire-fighting water supply networks and significantly reducing construction costs and water consumption.
