Spring-Loaded Safety Valve ISO9001 Certified for Water Steam Oil
Spring-Loaded Safety Valve ISO9001 Certified for Water Steam Oil
Specifications
Brand Name :
JGPV
Place of Origin :
China
MOQ :
1set
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
500 Set per month
Delivery Time :
14 days
Packaging Details :
Plywood box safety packing
Application: :
General
Certificate: :
ISO9001, ISO14001
Medium Type: :
Water, steam and oil etc.
Connection: :
Threaded / Flanged / Welded
Standard Or Non-Standard: :
Standard
Flow way: :
Two way
Actuation: :
Manual, Electric, Pneumatic,Automatic
Sealing Performance: :
Sealing
Working Temperature: :
Normal Temperature And High Temperature
Pressure Application: :
Normal Pressure
Quality Warranty: :
18 Months
Description

Highlight: Spring-loaded safety valve


Product introduction:


Safety valve, as the best device for extra-pressure protection, will automatically open and fully discharge to protect the equipment pressure from going on rise when medium’s pressure rises over the allowed valve and will automatically close when the pressure lowers to setting valve. This safety valve conforms with GB/T12243-2005 on its design, and flange connection dimensions of company with JB/T79-94 manufacture and acceptance etc. Technical standards. The bonnet of the sealed safety valve is enclosed in order to protect dust and other things from getting in and protect toxic and combustible medium from over-flow.and height of opening for a low lift safety valve 1/20-1/40 time the flow diameter.


Product technical parameters:


Nominal diameter DN(mm)

DN25

Nominal pressure PN(MPa)

1.6

Test pressure (MPa)

Strength test (Water)

2.4

Set pressure test (Air)

0.9

Main component

Body

1Cr18Ni9Ti

Bonnet

1Cr18Ni9Ti

Disc

1Cr18Ni9Ti

Spring

50CrVA

Stem

1Cr18Ni9Ti

Applicable medium

Water, air, petroleum gas and weak corrosive medium

Working temperature

≤300℃

Connection method

Flange connection

















Product features:


1. This type of safety valve designed for the equipment and pipeline of petroleum gas, air water and corrosive medium what the working temperature are less than 200℃.

2. Economic design with large displacement.

3. Disc is equipped with a backflush disc component, the plane structure of the disc and seat is easy to repair and rework.

4. Small setting pressure deviation, up to ±3%.

5. High quality spring steel, ensure the life and stability of the spring.

Our Advantages:


Spring-Loaded Safety Valve ISO9001 Certified for Water Steam Oil

Spring-Loaded Safety Valve ISO9001 Certified for Water Steam Oil

Spring-Loaded Safety Valve ISO9001 Certified for Water Steam Oil

Spring-Loaded Safety Valve ISO9001 Certified for Water Steam Oil

Spring-Loaded Safety Valve ISO9001 Certified for Water Steam Oil

Spring-Loaded Safety Valve ISO9001 Certified for Water Steam Oil
