The epoxy powder anti-corrosion process for the inner and outer walls of steel pipes is currently an efficient and reliable solution for pipeline anti-corrosion. The treated steel pipe has significant advantages: its coating not only has excellent corrosion resistance, capable of resisting the long-term erosion of various chemical media such as acids, alkalis and salts, but also has a smooth and dense surface structure, which can effectively reduce the frictional resistance during fluid transportation and improve the transmission efficiency of the pipeline. This type of anti-corrosion steel pipe, with its outstanding comprehensive performance, is widely used in multiple key fields such as long-distance oil and gas pipelines, urban water supply and drainage networks, and industrial fluid transportation.

Internal & External FBE Powder coating

Main equipment:

√ Full-process automation: One-click operation for feeding, sandblasting, heating, spraying and discharging, reducing human errors
√ High material utilization rate: The powder recovery system increases the raw material utilization rate to over 95%, which is environmentally friendly and economical
√ Customization capability: A team of 9 senior engineers supports personalized design of pipe diameter and coating process

Question & Answer:

Q1. Pipe Diameter Range?
A: 48-219mm / 219-1220mm / 325-1600mm / 508-2400mm / 1000-3200mm.

Q2. Descaling Grade?
A: SA2.5.

Q3. Coating Standards?
A: Complies with SY/T0413-2002 ,GB/T23257-2009, German DIN 30670 , NACE/AMPP, DNV, and CNPC38-2002.

Q4. Delivery Time?
A: 2-3 months after deposit confirmation.

Q5. Production Capacity?
A: Max. 3-8 km/day (varies by pipe size); Annual output: 2 million square meters m² (Φ508mm).

Q6. Coating Thickness?
A: 80-800 μm (customizable).

Q7. Export Countries?
A: Russia, UAE, India, Iran, Kazakhstan, Belarus, etc. (50+ lines installed globally).

Q8. Warranty & Support?
A: 12-month mechanical warranty / 6-month electrical warranty; Free training & technical guidance.
