High Speed Pert / Pex Flexible Insulation Pipe Making Machine for Industrial Fluid Transportation
High Speed Pert / Pex Flexible Insulation Pipe Making Machine for Industrial Fluid Transportation
High Speed Pert / Pex Flexible Insulation Pipe Making Machine for Industrial Fluid Transportation
High Speed Pert / Pex Flexible Insulation Pipe Making Machine for Industrial Fluid Transportation
Specifications
Brand Name :
Huashida
Model Number :
20-350mm
Certification :
CE, Rohs，TUV
Place of Origin :
China
MOQ :
1
Price :
US$150,000.00-2,000,000.00
Payment Terms :
T/T
Supply Ability :
50 Sets/Year
Delivery Time :
60Days
Packaging Details :
Standard Package
Usage :
Industrial Fluid Transportation
Specification :
1200.00cm *1000.00cm * 1000.00cm
Package Gross Weight :
1000.000kg
Description
High Speed PERT / PEX Flexible Insulation Pipe Making Machine For Industrial fluid transportation
Product Description

The flexible polyurethane pre-insulated pipe production line is an advanced equipment for producing polymer pressure inner pipes (PERT, PEX) and insulating the inner pipes with polyurethane foam.

The characteristic of this production line is that the pouring process of polyurethane foam is continuous.The inner pipe is continuously conveyed into the pouring area together with the polyurethane foam mixture, then coated and formed with a film, and then passed through a round die head to be coated with the outer protective layer extruded by the extruder.

High Speed Pert / Pex Flexible Insulation Pipe Making Machine for Industrial Fluid Transportation
Product Parameters

Compare between PE-RTII insulation pipe and Ordinary insulation pipe
Picture Weight/m Cost of project Pipe Length
High Speed Pert / Pex Flexible Insulation Pipe Making Machine for Industrial Fluid Transportation
Light
Low
unlimited
High Speed Pert / Pex Flexible Insulation Pipe Making Machine for Industrial Fluid Transportation

Weight

High

Fixed-lenghth
PE-RTII Heating Pipe Structure
High Speed Pert / Pex Flexible Insulation Pipe Making Machine for Industrial Fluid Transportation
  1. PERT Work pipe; 2- Protective pipe; 3-Insulated pipe; 4-Stander;
  2. d1- Protective pipe outer diameter; e1- Protective pipe wall thickness; e2- Insulation Layer thickness; dn-Work pipe Nominal diameter ;en- Nominal thickness of the work tube
Feature

PE-RTII insulation pipe

√ PERT II Pipes Can Tolerate Temperatures of 110°C
√ Pipeline smooth, no impurities, no pollution
√ Heating companies can realize unattended, automated operation
√ Low temperature heating
√ 60 °C supply water 45 °C backwater to meet the heating demand.
√ The construction is simple and convenient, and the excavation amount is 40%
√ Greatly reduce construction costs

It saves the raw materials for using PE-RT II pipe.
Example: Level 2 design pressure: 10 Bar; for cold and hot water transfer in buildings
Selection of different material pipes: the highest PE-RTIIS value; the thinnest wall thickness
Compared to PERT I, PERT II can reduce material use by 15%
Relative to PP-R, PERT II can reduce material use by 30%
Note: According to relevant Chinese national standards and draft

s Dia.(mm) Wall Thickness(mm) Wall Thickness Area(m2) Density(kg/m3) Length(m) Weight
(kg)		 Weight Save
PERT/X
PERT II S3.2 16 2.2 9.5E-05 947 1000 90
PERT I S2.5 16 2.7 1.1E-04 933 1000 105 -17%
PP-R S2 16 3.3 1.3E-04 900 1000 118 -31%

PERT II S3.2 20 2.8 1.5E-04 947 1000 143
PERT eI S2.5 20 3.4 1.8E-04 933 1000 165 -15%
PP-R S2 20 4.1 2.0E-04 900 1000 184 -29%

PERT II S3.2 25 3.5 2.4E-04 947 1000 224
PERT I S2.5 25 4.2 2.7E-04 933 1000 256 -14%
PP-R S2 25 5.1 3.2E-04 900 1000 287 -28%

PERT II S3.2 32 4.4 3.8E-04 947 1000 361
PERT I S2.5 32 5.4 4.5E-04 933 1000 421 -17%
PP-R S2 32 6.5 5.2E-04 900 1000 469 -30%
Detailed Photos

High Speed Pert / Pex Flexible Insulation Pipe Making Machine for Industrial Fluid Transportation

High Speed Pert / Pex Flexible Insulation Pipe Making Machine for Industrial Fluid TransportationHigh Speed Pert / Pex Flexible Insulation Pipe Making Machine for Industrial Fluid Transportation


Production Applications

Huashida's continuous PERT flexible insulated pipe pipes are ideal for a wide range of applications, including district heating, cooling systems, oil and gas pipelines, and industrial piping. Their superior insulation, anti-corrosion properties, and long service life make them the preferred choice for modern, sustainable piping systems.

High Speed Pert / Pex Flexible Insulation Pipe Making Machine for Industrial Fluid Transportation

Customer cases


High Speed Pert / Pex Flexible Insulation Pipe Making Machine for Industrial Fluid Transportation

Exhibition

High Speed Pert / Pex Flexible Insulation Pipe Making Machine for Industrial Fluid Transportation

Certifications

High Speed Pert / Pex Flexible Insulation Pipe Making Machine for Industrial Fluid Transportation

High Speed Pert / Pex Flexible Insulation Pipe Making Machine for Industrial Fluid Transportation
