Automatic PLC Controlled 3LPE Coating Pipe Production Line for 50-4200 mm Pipeline Diameter Anti-Corrosion
Automatic PLC Controlled 3LPE Coating Pipe Production Line for 50-4200 mm Pipeline Diameter Anti-Corrosion
Automatic PLC Controlled 3LPE Coating Pipe Production Line for 50-4200 mm Pipeline Diameter Anti-Corrosion
Automatic PLC Controlled 3LPE Coating Pipe Production Line for 50-4200 mm Pipeline Diameter Anti-Corrosion
Specifications
Brand Name :
Huashida
Model Number :
001
Certification :
CE, ISO, RoHS, REACH
Place of Origin :
China
MOQ :
1 set
Price :
150000-1000000
Payment Terms :
T/T
Supply Ability :
5-10 +sets+per mouth
Delivery Time :
60 days
Packaging Details :
Container loading，sea transportation
Coating Layers :
3 Layers
Control System :
PLC
Pipe Surface Preparation :
Shot Blasting
Origin :
China
Connection Type :
Welding
Operating Mode :
Automatic
Coating Structure :
Fbe, 2lpe, 3lpe
Coating Type :
Internal, External
Heating Method :
Induction Heating
Description

Product Description


3 Layer Polyethylene (3LPE) Anti-Corrosion Steel Pipe Production Line for Oil & Gas
3-layer polyethylene (3LPE) anti-corrosion steel pipe
3LPE anti-corrosion steel pipe consists of a three-layer structure, combining advanced technology and high-quality materials to provide excellent anti-corrosion protection for pipelines:
Base layer: epoxy powder coating, which is tightly bonded to the surface of the steel pipe and provides excellent anti-corrosion performance.
Middle layer: copolymer adhesive (with branched functional groups) to ensure that the base layer is firmly bonded to the surface layer.
Surface layer: high-density polyethylene (HDPE), providing mechanical protection, low water absorption and environmental adaptability.
Automatic PLC Controlled 3LPE Coating Pipe Production Line for 50-4200 mm Pipeline Diameter Anti-Corrosion
Our Advantages
Efficient sealing: extremely high sealing performance, long-term operation can significantly save energy, reduce costs and protect the environment.
Excellent anti-corrosion: strong corrosion resistance, simple and fast construction, and a service life of 30-50 years.
Low temperature adaptability: still has good corrosion resistance and impact resistance in low temperature environment.
Material characteristics: combined with the high strength of epoxy powder, the low water absorption of polyethylene and the flexibility of hot melt adhesive, it ensures high reliability.
Economical and efficient: simple production process, excellent anti-corrosion effect, high cost performance, and meets international standards.

Technical parameters
Pipeline diameter: 50-4200 mm
Processing capacity: ≥250 square meters/hour
Surface cleanliness: ≥Sa2.5
Production materials: epoxy powder, adhesive, polyethylene
Automatic PLC Controlled 3LPE Coating Pipe Production Line for 50-4200 mm Pipeline Diameter Anti-Corrosion
Automatic PLC Controlled 3LPE Coating Pipe Production Line for 50-4200 mm Pipeline Diameter Anti-Corrosion
Technological processes
Upload pipes→pipes screw conveyor→rust removal → intermediate frequency heating→Epoxy powder coating→outer layer adhesive polyethylene coating→cooling spray→pipes screw conveyor→grinding pipe ends→dowload pipes
Product Parameters
No.
Name
Specification
A. Surface Cleaning Equipment
1
Steel pipe conveyor
Adjustable speed and angle, pipe uploading and unloading controlled by PLC
2
Shot blasting machine

3
Cyclone dust collector
High efficient downwind cyclone dust removal
4
Impulse cartridge dust collector

5
Centrifugal fan

6
PLC control system
Automatic control of the line
B. Coating Equipment
1
Spiral pipe conveyor
Adjustable speed and angle
2
Induction heating machine

3
Powder spraying device
Spraying thickness 80-800μm
4
Automatic feeder&dryer

5
SJ-65/30 Extruder

6
SJ-180/30 Extruder

7
Adhesive extruder die mould
High quality die steel
8
PE sheet extruder die mold
High quality die stee
9
Adhesive/PE sheet coating device
Pressing roller with silicon coating and internal cooling
10
Environmental Protection Ventilation equipment

11
Cooling Spray equipment

C.Platform Equipment
1
Steel pipe platform
High quality
D.Groove Equipment
1
PE Beveling Machine
Steel brush disk,
2
Hydraulic Lifting and Turning Machinery
For lifting and turning the pipe
3
Hydraulic Equipment

Application

3LPE anti-corrosion coating is an ideal outer protective layer for buried pipelines and is widely used in:
Oil and gas transportation: natural gas and oil long-distance pipelines.
Urban gas supply: urban gas pipeline network.
Water supply pipeline: urban and industrial water supply system.
Other fluid transportation: chemical, sewage treatment and other pipeline systems.
Performance improvement: high electrical insulation, waterproof, wear-resistant, anti-aging, and enhanced pipeline mechanical properties.
Automatic PLC Controlled 3LPE Coating Pipe Production Line for 50-4200 mm Pipeline Diameter Anti-Corrosion
Company Profile

Qingdao Huashida Machinery Co., LTD., founded in 2003, is a global developer, manufacturer and solution provider of plastic extrusion equipment. 70% of its customers come from overseas countries such as Europe, America, the Middle East and Southeast Asia.
Welcome to our factory to discuss cooperation!
Automatic PLC Controlled 3LPE Coating Pipe Production Line for 50-4200 mm Pipeline Diameter Anti-Corrosion
