Specifications
Brand Name :
huashida
Model Number :
110-2200mm
Certification :
CE, ISO9001:2008
Place of Origin :
qingdao,china
MOQ :
1
Price :
US$200,000.00 - 1,000,000.00
Payment Terms :
L/C,D/P,Western Union
Supply Ability :
30 Sets/Year
Delivery Time :
60days
Packaging Details :
standard packaged
Screw No. :
Single-screw
Raw Material :
pe
HDPE Jacket Pipe Color :
Can Be Customized
Application :
Producing Pre-Insulated Pipe
Description
Puf Thermal Insulated HDPE Jacket Pipe Extruder Production Line
(Dia.110-2200mm)
Product Description

HDPE jacket pipe extrusion line is high-efficiency equipment with high speed and energy saving for producing HDPE pipe used as protective cover of PU foam thermal Pre-Insulated Pipe according to international standard.
HDPE jacket pipes are produced by vacuum calibration method, with smooth inner and outer walls, a long service life, good anti-corrosion and heat preservation performance, and excellent mechanical properties.
Pre-Insulated Pipe Production Line with HDPE Jacket Pipe Extruder for PU Foam Insulated Pipes Dia.110-2200mm Featuring Single-screw Extruder and Vacuum Calibration

Product Parameters


Style PE-110/500 PE-655/1380 PE-960/1860 PE-1155/2200
Main Extruder SJ-75/33 SJ-120/33 SJ-150/33 SJ-150/33
Pipe diameter Φ110-600mm Φ655-1380mm Φ960-1860mm Φ1155-2200mm
Capacity 250-350kg/h 700-900kg/h 1000-1200kg/h 1350kg/h
Installed power 160kw 480kw 580kw 650kw
Length 26m 36m 45m 48m

Production line composition:

-1set Vacuum loader
-1set Hopper dryer
-1set High-efficiency single screw extruder
-1set Vacuum calibration table
-1set Water spraying tank
-1set Hauling machine
-1set Cutting machine
-1set Discharging Frame
-1set PLC

Technical Highlights:
Single-screw extruder Precision temperature control system ensures consistent material fusion
Proprietary single-screw extruder optimized for polyethylene (PE) materials
Vacuum Calibration Patented vacuum calibration system replaces traditional internal pressure methods
Smart Automation Fully integrated PLC control system
Real-time process monitoring
Production Capabilities Diameter range: 110mm - 2200mm (customizable)
Output capacity: 250-1600 kg/h (material-dependent)


Our Advantages

Features of the HDPE sleeve production line:

1.small dimension
2.high degree of automation, can be operated by one person, saving labor costs
3.long service life.
4.high-efficiency extruder gives larger output, stable performance
5.pipe wall is average and smooth
6.no waste of raw material
7.One-time molding
Pre-Insulated Pipe Production Line with HDPE Jacket Pipe Extruder for PU Foam Insulated Pipes Dia.110-2200mm Featuring Single-screw Extruder and Vacuum CalibrationPre-Insulated Pipe Production Line with HDPE Jacket Pipe Extruder for PU Foam Insulated Pipes Dia.110-2200mm Featuring Single-screw Extruder and Vacuum CalibrationPre-Insulated Pipe Production Line with HDPE Jacket Pipe Extruder for PU Foam Insulated Pipes Dia.110-2200mm Featuring Single-screw Extruder and Vacuum Calibration

Pre-Insulated Pipe Production Line with HDPE Jacket Pipe Extruder for PU Foam Insulated Pipes Dia.110-2200mm Featuring Single-screw Extruder and Vacuum Calibration
Pre-Insulated Pipe Production Line with HDPE Jacket Pipe Extruder for PU Foam Insulated Pipes Dia.110-2200mm Featuring Single-screw Extruder and Vacuum Calibration


Pre-Insulated Pipe Production Line with HDPE Jacket Pipe Extruder for PU Foam Insulated Pipes Dia.110-2200mm Featuring Single-screw Extruder and Vacuum Calibration
Qingdao Huashida Machinery Co., LTD., founded in 2003, is a global developer, manufacturer and solution provider of plastic extrusion equipment. 70% of its customers come from overseas countries such as Europe, America, the Middle East and Southeast Asia.
