Super Wide 8000mm Max Width 0.5-2.0mm Film Thickness Geomembrane Film Extrusion Line
Super Wide 8000mm Max Width 0.5-2.0mm Film Thickness Geomembrane Film Extrusion Line
Super Wide 8000mm Max Width 0.5-2.0mm Film Thickness Geomembrane Film Extrusion Line
Super Wide 8000mm Max Width 0.5-2.0mm Film Thickness Geomembrane Film Extrusion Line
Specifications
Brand Name :
huashida
Certification :
CE, ISO9001:2008, QS, ISO
Place of Origin :
qingdao,China
MOQ :
1
Price :
US$200,000.00 - 250,000.00
Payment Terms :
D/P,D/A,T/T
Supply Ability :
30 sets/year
Delivery Time :
60 days
Screw :
Single-Screw
Computerized :
Computerized
Customized :
Customized
Specification :
sj120/33, sj200/33
Automation :
Automatic
Product Type :
Extrusion Molding Machine
Transport Package :
Standard Package
Screw Channel Structure :
Deep Screw
Film Thickness :
0.5-2.0mm
Exhaust :
Don't Exhaust
Description
Product Description


Water-proof Coiled Material/GEO-membrance Film Extrusion Line is a super-large water-proof Coiled material. The mainly material for the film is varioius kinds of polymer, such as PE, PP, PET, PVC, EVA etc. The max width is 8000mm, the thickness from 0.1 to 3.0mm. In order to meet different customers with different requirements, other auxiliary equipment could be arranged.

Super Wide 8000mm Max Width 0.5-2.0mm Film Thickness Geomembrane Film Extrusion Line

Features

1. Width and thickness can be adjusted by online set.
2. High strenght and thoughness.
3. Excellent stress cracking resistance.
4. Large temperature range.
5. Easy operation for construction.
6. Other undergound works and complex terrain.

Super Wide 8000mm Max Width 0.5-2.0mm Film Thickness Geomembrane Film Extrusion Line


Applications

Landfill sites and solid waste disposal projects

Wastewater treatment plants and sewage systems

Subway construction and underground rail projects

Tunnel waterproofing and lining works

Artificial lakes, ponds, and landscape water features

Reservoirs, dams, and water conservation projects

Industrial waterproofing and anti-seepage projects

Mining projects and heap leach pads

Other civil engineering and underground construction works

Product Parameters


Extruder Film Width Film Thickness Capacity Total Power Dimension(m)
SJ120/33 3000mm 0.5-2.0mm 500kg/h 250kw 20x4x2.5
SJ200/33 8000mm 0.8-3.0mm 1200kg/h 550kw 22x10x2.5

Super Wide 8000mm Max Width 0.5-2.0mm Film Thickness Geomembrane Film Extrusion Line

Company Profile
Qingdao Huashida Machinery Co., LTD, is a manufacturer of series of plastic pipe machines, municipal pipe machines, pipe insulation&anticorrosion machines, and pipe jointing&anticorrosion materials, with 21 years of production experience.
Our main products are:
1. HDPE jacket pipe for pre-insulated pipe Production Line (110-2000mm)
2. Rigid pre-insulated pipe Production Line
3. Flexible pre-insulated pipe(PERT) production line
4. Steel pipe FBE/2LPE/3LPE anti-corrosion coating line
5. Steel pipe derusting line
6. PE pressure pipe/Water Gas supply pipe production line
6. PP/PE plastic board/sheet/geomembrane production line
7. NBR PVC Thermal insulation tube/plate production line
8.Pipeline anti-corrosion materials and instruments: heat shrink joint coating sleeve, electro-fusion weldable joint sleeve, portable welding gun(extruder), PE PP welding rod.
We have been working with more than 400 overseas customers and exporting our products to Kazakhstan, Uzbekistan, Iran, Turkey, Russia, Nigeria and other countries.

Super Wide 8000mm Max Width 0.5-2.0mm Film Thickness Geomembrane Film Extrusion Line
Our team
Super Wide 8000mm Max Width 0.5-2.0mm Film Thickness Geomembrane Film Extrusion Line
Delivery
Super Wide 8000mm Max Width 0.5-2.0mm Film Thickness Geomembrane Film Extrusion Line
Exhibition
Super Wide 8000mm Max Width 0.5-2.0mm Film Thickness Geomembrane Film Extrusion Line
Certifications
Super Wide 8000mm Max Width 0.5-2.0mm Film Thickness Geomembrane Film Extrusion LineSuper Wide 8000mm Max Width 0.5-2.0mm Film Thickness Geomembrane Film Extrusion Line
