Specifications
Brand Name :
huashida
Model Number :
Coating Production Line
Certification :
CE, ISO, RoHS
Place of Origin :
Qingdao, China
MOQ :
1
Price :
US$100,000.00-300,000.00
Payment Terms :
D/A,D/P,T/T,Western Union
Supply Ability :
30 Sets/Year
Delivery Time :
60days
Packaging Details :
Plastic Film and Wooden Pallet
Coating :
Powder Coating
Pipe Surface Treatment :
No Less Than SA2.5
PE Thickness :
2-3mm
Material :
HDPE ,Adhesive,Epoxy Powder
Description

O-Type Steel Pipe Extrusion Coating Line for 3LPE 2LPE FBE Anti-Corrosion

Product Description
O-Type Extrusion Coating Line for 3LPE Anti-Corrosion Pipe with Powder Coating and SA2.5 Surface Treatment
A complete set of O-type Extrusion Anti-Corrosion 3LPE 2LPE FBE Coating Machine includes systems of steel pipe transmission, shot blasting, dust collector, pipe heating, electrostatic spraying powder, PE and adhesive coating, water cooling, edge cutting, hydraulic and pneumatic device, detecting and electric controlling system.

Round-extrusion 3LPE anti-corrosion coated steel pipe has good chemical resistance: it can resist the erosion of a variety of chemical media,,such as acids, bases, salts, oxidants, etc,suitable for medium transportation in different environments,prolong the service life of steel pipe. This kind of anti corrosive steel pipe is widely used in oil, natural gas transmission pipelines, water supply and drainage pipelines and many other fields.


O-Type Extrusion Coating Line for 3LPE Anti-Corrosion Pipe with Powder Coating and SA2.5 Surface Treatment

Technological processes

Upload pipes→pipes screw conveyor→rust removal→intermediate frequency heating→Epoxy powder coating→outer layer adhesive polyethylene coating→cooling spray→pipes screw conveyor→grinding pipe ends→unload pipes

Our Advantages

Advantages of O-shaped extruded 3LPE anti-corrosion coated steel pipe:
1. Good chemical resistance
2. It can resist the erosion of various chemical media, such as acids, alkalis, salts, oxidants, etc., and is suitable for the transportation of media in different environments, thus extending the service life of steel pipes
3. It is widely applied in many fields such as oil and gas transportation pipelines, water supply and drainage pipelines, etc

Main equipment list

No. Name Set
A. Derusting Equipment
1 Pipe-converying Equipment 1
2 Shot Blast Cleaning Machine 1
3 Cyclone Dust Collector 1
4 Pulse dust collector 1
5 Centrifugal exhaust fan 1
6 Rust removal equipment PLC control system 1
B. Coating equipment
1 Coating transfer equipment 1
2 IF heating device 1
3 Powder spraying device 1
4 Automatic loading dryer 2
5 SJ-65/30 Extruder 1
6 SJ-90/30 Extruder 1
7 Hot melt adhesive extruder die 1
8 PE extruder head mold 1
9 Hot melt adhesive/PE coating device 1
10 Cooling Spray equipment 1
C.Platform Equipment
1 Steel pipe platform 1
2 Post-rust removal transition platform 1
3 Product tube storage platform 1
4 Hydraulic Equipment 2
D.Groove Equipment
1 PE Beveling Machine 2
2 Hydraulic Lifting and Turning Machinery 1
3 Hydraulic Equipment 1
O-Type Extrusion Coating Line for 3LPE Anti-Corrosion Pipe with Powder Coating and SA2.5 Surface Treatment
O-Type Extrusion Coating Line for 3LPE Anti-Corrosion Pipe with Powder Coating and SA2.5 Surface Treatment
O-Type Extrusion Coating Line for 3LPE Anti-Corrosion Pipe with Powder Coating and SA2.5 Surface Treatment
O-Type Extrusion Coating Line for 3LPE Anti-Corrosion Pipe with Powder Coating and SA2.5 Surface Treatment

Shipment


O-Type Extrusion Coating Line for 3LPE Anti-Corrosion Pipe with Powder Coating and SA2.5 Surface TreatmentO-Type Extrusion Coating Line for 3LPE Anti-Corrosion Pipe with Powder Coating and SA2.5 Surface TreatmentO-Type Extrusion Coating Line for 3LPE Anti-Corrosion Pipe with Powder Coating and SA2.5 Surface Treatment


Qingdao Huashida Machinery Co., LTD., founded in 2003, is a global developer, manufacturer and solution provider of plastic extrusion equipment. 70% of its customers come from overseas countries such as Europe, America, the Middle East and Southeast Asia.
Welcome to our factory to discuss cooperation!
