Specifications
Principle :
High-Pressure Air Type
Certification :
CE,ISO
Pipe Structure :
Carrier Steel Pipe-Polyurethane Foam-HDPE Casing
Model Number :
Polyurethane Foam Machine
Supply Ability :
30 Sets/Year
MOQ :
1
Delivery Time :
60DAYS
Payment Terms :
L/C,D/P,T/T
Price :
US$1,000,000.00-1,300,000.00
Coating :
Powder Coating
Brand Name :
HUASHIDA
Packaging Details :
Wodden Box
Application :
Hot Chiller Water/Oil /Chemical Material Pipeline
Place of Origin :
QINGDAO,CHINA
Description


Automated Pre-Insulated Pipe Production Line with

High-Pressure Air Type Polyurethane Spray Foam

Product Description

The polyurethane sprayed polyethylene thermal winding preinsulation pipe production line, independently developed by Huashida, is composed of three main sections: the external shot blasting and derusting collector production line, the polyurethane spraying production line, and the PE winding production line. This production line holds numerous national patents and has been rated as having a technology advanced level of 5 by a third-party standardized evaluation, indicating that it has reached the domestic leading level. It has also been awarded the first set of technical equipment in Shandong Province.

The production line utilizes a continuous spraying process, characterized by high automation, rapid production efficiency, and raw material savings. It also features an increased foaming and closed cell rate, a lower water absorption rate, trinity molding, and enhanced reliability. The products manufactured are low-carbon and environmentally friendly, offering significant economic and social benefits.


Producing technology flow of the polyurethane coating steel preinsulated pipe equipment:

1. Remove rust from steel pipe surface

2. preheat the steel pipe to get it ready for polyurethane spraying

3. Spray polyurethane evenly on steel pipe outer surface

4. Wrap melted HDPE strap around the PU foam

5. Trim the pipe ends

Automated Pre-Insulated Pipe Production Line with High-Pressure Air Type Polyurethane Spray Foam
Technical Features:
1. Dust removal meets environmental standards(The three-level dust removal )
2. Suitable for the production of large-diameter insulation pipes
3. Automated operation of production lines
4. Spraying saves materials
5. Efficient extrusion of pipelines
6. Automated precision machining of pipeline interfaces

Advantage:
Awarded the first (set) technical equipment in Shandong Province
Evaluation Report on Standardization of Scientific and Technological Achievements in Qingdao City
Having multiple national patents
Automated Pre-Insulated Pipe Production Line with High-Pressure Air Type Polyurethane Spray Foam
Automated Pre-Insulated Pipe Production Line with High-Pressure Air Type Polyurethane Spray Foam
Product Parameters
Steel pipe diameter Thickness of insulation pipe Diameter of outer protective tube Minimum wall thickness of outer protective layer
500 30-60 580-640 5.6
630 30-60 710-772 6.6
710 30-60 790-850 7.2
800 30-60 885-950 7.9
900 30-60 980-1054 8.7
1000 30-60 1090-1155 9.4
1100 30-60 1190-1250 10.2
1200 40-100 1316-1436 11
1400 50-100 1538-1638 12.5
1500 50-100 1638-1738 12.5

Detailed Photos

Production line equipment Photos show

Automated Pre-Insulated Pipe Production Line with High-Pressure Air Type Polyurethane Spray Foam
Rust Removal
Automated Pre-Insulated Pipe Production Line with High-Pressure Air Type Polyurethane Spray Foam

PE film jacket wrapping
Automated Pre-Insulated Pipe Production Line with High-Pressure Air Type Polyurethane Spray Foam

PE Jacket Water quenching
Automated Pre-Insulated Pipe Production Line with High-Pressure Air Type Polyurethane Spray Foam

Qingdao Huashida Machinery Co., Ltd was established in 2003. Since its inception, Huashida has focused on plastic polyurethane insulation pipe production line, 3LPE anticorrosion pipe production line, large diameter underground pipe production line and plastic pipe joints for 20 years. We always attach great importance to research and development,collaborating closely with Beijing University of chemical technology, Qingdao university of technology and scientific research institutions. by absorbing advanced technology home and abroad, after 22 years of endeavor we now rank one of the top 3 manufacturers in the industry in China. Huashida machines have been well received in Saudi Arabia, Kazakhstan, Uzbekistan, United Arab Emirates, Turkey, Russia, etc.

Welcome to our factory to discuss cooperation!
