V Shaped 40mm*2mm 4Kw CNC Pipe Bending Machine
V Shaped 40mm*2mm 4Kw CNC Pipe Bending Machine
Specifications
Model Number :
TM40
Supply Ability :
100
Payment Terms :
30% tt in advance 70% blance shipped out
MOQ :
1
Packaging Details :
wood case
Delivery Time :
30days
Place of Origin :
china
Brand Name :
CAOS
Price :
Negotiation
Model NO. :
10cnc
Customized :
Customized
Advantage :
Work Flexible
Condition :
New
Max Suitable Pipe :
40*2
Max Work Schedule :
100
Hydraulic Power :
4.5MPa
Working Speed :
100mm in 3--4 Sec
Technical :
Cold Forming
Efficiency :
High
Automatic :
High
Usage :
End Forming
Using Range :
Metal Pipes
Function :
Pipe Bending
Field :
Machinery
Color :
Customized
Control :
CNC Control
Fuse :
Chnt
Trademark :
CAOS
Transport Package :
Wood
Specification :
TK-10CNC
Origin :
China
HS Code :
8401200000
Port :
Shanghai, China
Type :
Hydraulic Machine
Forging Forming Method :
Forming
Power Source :
Hydraulic Pressure
Feature :
Automation
Certification :
ISO9001, CE
Warranty :
12 Months
Description

TK-10 CNC pipe bending machine/tube bending machine with CNC

A kind of high efficiency, full-auto machine
Tube clamping and end forming driven by hydraulic
Available end forming: oncave-convex section, long, flat, square, enlargement, slanting, V-shaped, open slot and others
Good mechanical parts ensure machine runs in high stability.
Simple die change process.
CE, ISO9001 Certification
Specification

Name		 Unit TK-10CNC
Max. End Forming Capacity Mm 40*2
Max. End Forming Length mm 100
Reduction time mm/s 100/3-4
Max. Hydraulic Pressure Mpa 12
Motor Power Kw 4
Dimension of machine mm 2400*650*1350
Weight of the machine kg 1100

Configuration

NAME		 Supplier
Hydraulic Motor Wuxi Taihu
Hydraulic Valve Japan Yuken
Over-flow Valve Japan Yuken
Adjustable Valve Japan Yuken
Sealing Element Taiwan Ding Zing
PLC Japan Omron
Touch Screen Taiwan Weinview
Contactor CHNT
Over-Thermal Relay CHNT
Transformer CHNT
Fuse CHNT
Proximity Switch Taiwan YANGMING
Oil Tube Taiwan Lianhui
