ASTM Seamless Carbon Steel Pipe Hot Rolled Cold Rolled Fire Fighting Pipes
ASTM Seamless Carbon Steel Pipe Hot Rolled Cold Rolled Fire Fighting Pipes
ASTM Seamless Carbon Steel Pipe Hot Rolled Cold Rolled Fire Fighting Pipes
ASTM Seamless Carbon Steel Pipe Hot Rolled Cold Rolled Fire Fighting Pipes
Specifications
Brand Name :
BaoYang
Model Number :
ASTM/DIN/GB/EN/JIS
Certification :
CE & ISO
Place of Origin :
cangzhou
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Delivery Time :
7~30 working days
Packaging Details :
Standard Export Packing
Name :
Seamless Carbon Steel Pipes
Process :
Hot Rolled Cold Rolled Cold Drawn
Standards :
ASTM/DIN/GB/EN/JIS
Material :
Carbon Steel
Wall Thickness :
1-20mm (0.04 Inch - 0.78 Inch)
Outer Diameter :
6-2500mm
Processing Service :
Bending, Punching, Cutting
Usage :
Pipeline Transport, Oil/Gas Drilling, Machinery Industry
Description

ASTM Seamless Steel Pipes for Fire Fighting Applications:

Product Description: ASTM Seamless Steel Pipes for fire fighting purposes are precision-engineered tubes designed to meet the rigorous demands of fire protection systems. These pipes are manufactured in accordance with ASTM standards, which ensure a high level of quality, durability, and reliability. They are seamless, meaning they are produced without a weld, providing a continuous material structure that is critical for the safety and performance of fire fighting equipment.

Product Parameter Specifications:

Parameter Specification Units
Standard ASTM A53/A53M, ASTM A106/A106M, ASTM A334/A334M, etc. -
Outer Diameter Ranges from 1/8" to 12" depending on the specific ASTM standard in
Wall Thickness Varies with diameter and pressure class in or mm
Length Standard lengths available; custom lengths upon request ft or m
Tolerance As per ASTM standards for diameter, wall thickness, and length -

Product Applications:

  1. Fire Protection Systems: Used in fire sprinkler systems for commercial and residential buildings.
  2. Hydraulic Systems: Suitable for water and hydraulic fluid transport in various industrial applications.
  3. Piping Networks: Ideal for the construction of piping networks that require high-pressure water flow.
  4. Marine and Offshore: Employed in marine fire fighting systems and offshore platforms.
  5. Infrastructure: Utilized in urban infrastructure for water supply and distribution.

Types of ASTM Seamless Steel Pipes for Fire Fighting:

  • ASTM A53 Grade A and B: Standard weight pipes for general purposes.
  • ASTM A106 Grade B: Medium pressure pipes for higher temperature applications.
  • ASTM A334 Grade 6: High-strength seamless steel pipes for low-temperature applications.
  • Other Special Grades: May include specialized grades for corrosive environments or high-pressure systems.

Mechanical Properties:

Property Typical Range/Value for ASTM A53 Grade B Units
Tensile Strength 340-485 MPa MPa
Yield Strength ≥ 205 MPa (for nominal wall thickness ≤ 0.5 in) MPa
≥ 190 MPa (for nominal wall thickness > 0.5 in) MPa
Elongation ≥ 20% in 2 in or 50 mm length %

Chemical Composition:

Element Typical Range (%) for ASTM A53 Grade B
Carbon (C) 0.29 max
Manganese (Mn) 0.90 max
Phosphorus (P) 0.035 max
Sulfur (S) 0.035 max
