China Factory SB-38CNC-2A-1S Steel Pipe Bend and Bending Machine Chair Bending Process
China Factory SB-38CNC-2A-1S Steel Pipe Bend and Bending Machine Chair Bending Process
China Factory SB-38CNC-2A-1S Steel Pipe Bend and Bending Machine Chair Bending Process
China Factory SB-38CNC-2A-1S Steel Pipe Bend and Bending Machine Chair Bending Process
China Factory SB-38CNC-2A-1S Steel Pipe Bend and Bending Machine Chair Bending Process
China Factory SB-38CNC-2A-1S Steel Pipe Bend and Bending Machine Chair Bending Process
China Factory SB-38CNC-2A-1S Steel Pipe Bend and Bending Machine Chair Bending Process
China Factory SB-38CNC-2A-1S Steel Pipe Bend and Bending Machine Chair Bending Process
China Factory SB-38CNC-2A-1S Steel Pipe Bend and Bending Machine Chair Bending Process
China Factory SB-38CNC-2A-1S Steel Pipe Bend and Bending Machine Chair Bending Process
China Factory SB-38CNC-2A-1S Steel Pipe Bend and Bending Machine Chair Bending Process
China Factory SB-38CNC-2A-1S Steel Pipe Bend and Bending Machine Chair Bending Process
China Factory SB-38CNC-2A-1S Steel Pipe Bend and Bending Machine Chair Bending Process
China Factory SB-38CNC-2A-1S Steel Pipe Bend and Bending Machine Chair Bending Process
Specifications
material / metal processed :
Alloy, Brass / Copper, Carbon Steel, Stainless Steel, PVC, Aluminum
bending radius (mm) :
15 - 200
max. bending angle (deg) :
190
bending precision (deg) :
0.1
Place of Origin :
Jiangsu, China
Brand Name :
cedar
automation :
Automatic
extra services :
Cnc Pipe Bending Machine
power (kw) :
4
weight (kg) :
1800
warranty :
1 Year
key selling points :
High-Accuracy
machinery test report :
Provided
video outgoing-inspection :
Provided
core components :
Bearing, Pump, Gear, PLC, Feeding trolley floating structure, Electric control cabinet, IO detection
The oil pump motor :
4.0KW
Machine dimension mm :
4200X900X1300
Feeding accuracy :
±0.1MM
Precision of Angle :
±0.1°
Pipe bending precision :
±0.1°
Maximum square iron tube :
32*1.5mm
Angle servo motor power :
0.75KW
Oil pump motor power :
4.0KW
Feeding servo motor :
1.0KW
Maximum pressure :
12Mpa
Condition :
New
Applicable Industries :
Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company, Other
Showroom Location :
None
Marketing Type :
New Product 2020
Warranty of core components :
1 Year
Year :
2021
MOQ :
1 set
Price :
$2,060-2,150 / set
Description

China Factory SB-38CNC-2A-1S Steel Pipe Bend and Bending Machine Chair Bending ProcessChina Factory SB-38CNC-2A-1S Steel Pipe Bend and Bending Machine Chair Bending ProcessChina Factory SB-38CNC-2A-1S Steel Pipe Bend and Bending Machine Chair Bending ProcessChina Factory SB-38CNC-2A-1S Steel Pipe Bend and Bending Machine Chair Bending ProcessChina Factory SB-38CNC-2A-1S Steel Pipe Bend and Bending Machine Chair Bending ProcessChina Factory SB-38CNC-2A-1S Steel Pipe Bend and Bending Machine Chair Bending ProcessChina Factory SB-38CNC-2A-1S Steel Pipe Bend and Bending Machine Chair Bending ProcessChina Factory SB-38CNC-2A-1S Steel Pipe Bend and Bending Machine Chair Bending Process

The machine parameters:

project unit SB-38CNC4A-2S with bending
Maximum Bending carbon steel pipe (1.5D) mm 38*3.0
Maximum bending stainless steel tube(2.0D) mm 32*1.5
The controller Industrial PC With 3d motion simulation function
Maximum bending Angle ° 190
Maximum number of molds installed Set of 2
The number of bends per pipe fitting can be set A most36
Maximum feeding length mm 2500
Maximum bending radius mm 180
Minimum bending radius mm Acuity 1.2 D
Bend servo motor KW 3/4
Feeding servo motor KW 1.0
Angular servomotor KW 4.0
Head translation servo motor power KW 0.75
reducer DS 180
Pipe bending precision ° ±0.1
Precision of Angle ° ±0.1
Feeding accuracy mm ±0.1
Pipe bending speed Degree/SEC. 80
Corner speed Degree/SEC. 180
Feeding speed Mm/SEC. 1000
The oil pump motor KW 4.0
Maximum pressure Mpa 12 adjustable
The hydraulic cylinder Mpa Maximum 18, inner hole roughness ≤0.4
Fuel tank capacity KG 250
Machine weight KG 1500
The machine size mm 3830*760*1200

China Factory SB-38CNC-2A-1S Steel Pipe Bend and Bending Machine Chair Bending ProcessChina Factory SB-38CNC-2A-1S Steel Pipe Bend and Bending Machine Chair Bending ProcessChina Factory SB-38CNC-2A-1S Steel Pipe Bend and Bending Machine Chair Bending ProcessChina Factory SB-38CNC-2A-1S Steel Pipe Bend and Bending Machine Chair Bending ProcessChina Factory SB-38CNC-2A-1S Steel Pipe Bend and Bending Machine Chair Bending Process

FAQ

Choose us

Q: How to quickly choose the most suitable product for you?

A: You can check it on the product page, or contact customer service at +8618021646346 to tell the following details: What machine do you need? The size, thickness, material, and processing requirements of the workpiece, it is best to have a drawing of the workpiece, and we will provide a more professional machine according to your requirements.

Payment method

Q: What are your payment terms?

A: We support T/T, L/C, etc. TT, 30% in advance, and the balance 70% before shipment.

Delivery guarantee

Q: What is the delivery time?

A: Usually in stock, if you need to order fixtures and molds, we usually complete it within 7-15 working days. For customized products, please contact customer service to determine the exact time.

Use guarantee

Q: When I bought this machine, I didn't know how to use it. what do I do?

A: We will send English manuals, installation and operation videos with the equipment. If you still have questions, we can talk via phone, Whatsapp, WeChat and email.

Quality assurance

Q: How to ensure quality?

A: We have factories. We are industry experts and have been operating for more than 10 years. We always adhere to the policy of "high quality, all-round service".

Warranty service

Q: How long is the warranty period?

A: Within one year from the date of leaving the factory, if the part fails or is damaged

(Due to quality problems, wearing parts are excluded), our company provides these parts for free.

Company visit

Q: How do we reach your company?

A: Our company is located in Zhangjiagang City, Jiangsu Province, near Shanghai. You can fly directly to PVG Airport or Shanghai Hongqiao Airport. Welcome to visit our company.
