High Accuracy Automatic Pipe Hole Punching Machine Press metal Hole Piercing Machine

HYRAULIC CYLINDER SERVO MOTOR FEEDING ROTAION STEEL METAL TUBE PIPE HOLE PUNCHING MACHINE

• Touch Screen settings, CNC control system, precise servo motor positioning, module storage memory function.
• Structure:Steel plate welded structure,Hydraulic cylinder system
• Mould replacement: change the die easily without adjusting the dies to reduce the mould damage rate and pipe fittings rejection rate due to the dies setting error.

Skilled workers can change the mould within 10 minutes.

Punching Category:

1. .single hole punching;
2. Multi hole punching;
3. Isometric hole punching;
4. none- Isometric hole punching;
5. rotary punching.

• Advantages: The advantages of automatic metal pipe punching machine are mainly manifested in the following aspects:

  · Improve production efficiency: Automated processing can greatly reduce labor costs and improve production efficiency.

  · Ensure processing accuracy: high-precision processing technology can ensure the quality and stability of products.

  · Enhanced processing flexibility: holes of different shapes and sizes can be processed according to customer requirements.

  · Reduce processing costs: Fully automated processing can reduce processing costs and improve enterprise competitiveness.

• Hydraulic and Servo System.
• Pipe feeding+Pipe rotation mode:Servo motor+reducer​

Description

Mitsubishi servo system

·Schneider Electric

Adjustable drive system

Punch Needle

By using our Liye company’s high-precision automatic multi-size hole pipe punching machine, we can punch out a variety of hole shapes at one time. The equipment uses the Japanese Mitsubishi servo system to control the movement and rotation of the pipe forwards and backwards, to achieve high-precision multi-size hole’s isometric ,unequal space, rotary punching. The quality stability of mass production is very high, the production efficiency is 5-6 times higher than that of the traditional process, and the safety is also greatly improved.
