Compressed Biscuit Food Making Machine ZPW-4-4 ZPW-4-2
Compressed Biscuit Food Making Machine ZPW-4-4 ZPW-4-2
Compressed Biscuit Food Making Machine ZPW-4-4 ZPW-4-2
Compressed Biscuit Food Making Machine ZPW-4-4 ZPW-4-2
Compressed Biscuit Food Making Machine ZPW-4-4 ZPW-4-2
Compressed Biscuit Food Making Machine ZPW-4-4 ZPW-4-2
Compressed Biscuit Food Making Machine ZPW-4-4 ZPW-4-2
Compressed Biscuit Food Making Machine ZPW-4-4 ZPW-4-2
Specifications
Brand Name :
Tianfeng
Model Number :
ZPW-4-4 ZPW-4-2
Certification :
CE/ISO
Place of Origin :
Shanghai, China
MOQ :
1 unit
Price :
Welcome to consult
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10 units/month
Delivery Time :
45 working days
Packaging Details :
export wooden case
Voltage :
220V/380V, 50HZ/60HZ
Condition :
New
Warranty :
1 year
After-sales service provided :
Engineers available to service machinery overseas
Power(w) :
7.5-11KW
Type :
rotary type, Tablet Pressing Machine, High capacity output, ZPW15D ZPW17D ZPW19D granules powder Tablet Press Machine
Function :
pill press tablet press machine,power press punching, compressed biscuit making
Capacity :
7680 pic/h
Power source :
Hydraulic,Electric
Application :
compressed biscuit making
Pressure :
100-250KN
Description

ZPW-4-4 ZPW-4-2 food making machine ZPW-4-2 compressed biscuit machine

Compressed biscuit machine recycles broken biscuits. The machine is easily operated due to photoelectric tracking, and driven by pneumatic and hydraulic system. It gets biscuit scraps as raw material, mixing with other nutritious ingredients and flavors, then make them compressed to pieces.


Technical Parameters of Rotary Tablet Press

TYPE ZPW-4-4 ZPW-4-2
Max. Compression Pressure 180-250 180-250
Max. Dia. of Tablet(mm) According to customer’s requirement According to customer’s requirement
Max. Filling Depth (mm) 40 (Adjustable) 40 (Adjustable)
Max. Thickness of Tablet(mm) 10-30 10-30
Maximum Working Diameter (mm) 1030 750
Turret Speed(r/min) 7 8
Production Capacity(pc/h) 6720 3840
Motor(Kw) 7.5-11KW 7KW
Overall Size(mm) 1750*1200*1810 1240*920*1710
Net Weight(Kg) 2000 2500

Compressed Biscuit Food Making Machine ZPW-4-4 ZPW-4-2Compressed Biscuit Food Making Machine ZPW-4-4 ZPW-4-2

Compressed Biscuit Food Making Machine ZPW-4-4 ZPW-4-2Compressed Biscuit Food Making Machine ZPW-4-4 ZPW-4-2Compressed Biscuit Food Making Machine ZPW-4-4 ZPW-4-2

Our Services

Pre-Sales Service

* Inquiry and consulting support.
* Sample testing support.
* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
