KR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well Drilling
KR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well Drilling
KR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well Drilling
KR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well Drilling
KR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well Drilling
KR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well Drilling
KR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well Drilling
KR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well Drilling
Specifications
Brand Name :
Tysim
Model Number :
KR250CS
Certification :
CE/ISO900A
Place of Origin :
jiangsu，China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
30 sets per month
Delivery Time :
45 working days after received your payment
Packaging Details :
Nude packing and overall transport by sea with roll-on-roll-off ship; One Flat rack container.
Max. Torque :
250kN.m
Max. drilling diameter :
2000mm
Weight :
69t
Description

KR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well Drilling

​

KR250CS
  Performance Parameter Unit Value
  Max. torque kN.m 250
  Max. drilling diameter mm 2000
  Max. drilling depth m 31.2
  Working speed rpm 6~26
  Max. cylinder pressure kN 220
  Max. hoist capacity kN 220
  Main winch pull force kN 230
  Main winch speed m/min 80
  Auxiliary winch pull force kN 110
  Auxiliary winch speed m/min 75
  Max. cylinder stroke mm 2000
  Mast side raking ° ±5
  Mast raking forward ° 5
  System pressure mpa 35
  Pilot pressure mpa 3.9
  Max. walking speed km/h 1.5
  Max. pull force kN 510
  Operating height mm 10915
  Operating width mm 4300
  Transport height mm 3395
  Transport width mm 3000
  Transport length mm 10645
  Total weight t 69

  Engine performance
  Engine type   QSL9
  Engine form   Water cooled, six cylinder line, turbocharged
** Cylinder number*cylinder diameter*stroke mm 6*114*145
  Displacement L 8.9
  Rated power kw/rpm 232/1900
  Max. torque N.m/rpm 1424/1500
  Emission standard   EU

  Kelly bar
  Model   Interlocking
(mm) Outer diameter   φ650
*(m) Layers*Length of each section   8*5.3
(m) Max.depth   31.2

  Chassis
(~) Track width mm 3000~4500
  Width of track plate mm 800


KR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well DrillingKR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well DrillingKR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well DrillingKR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well Drilling

​​​

KR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well DrillingKR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well DrillingKR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well DrillingKR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well Drilling

​​

KR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well DrillingKR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well DrillingKR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well DrillingKR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well Drilling

​

KR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well DrillingKR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well DrillingKR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well DrillingKR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well Drilling

​​

​

KR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well DrillingKR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well DrillingKR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well DrillingKR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well Drilling

​KR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well Drilling

KR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well Drilling

KR250CS Hydraulic Rotary Piling Rig Driver Construction Equipment Well Drilling

Why Choose Us?
1. We are the professional & trustworthy manufacturer of piling machinery in China, best quality & best service.
2. Supply professional customized service to meet all your requirements.
3. Our rotary drilling rigs have been sold to more than 20 counstries, such as Russia, Australia, Thailand, Zambia and others.
4. Competitive price.

FAQ

Q1: What is the Warranty of the Rotary Drilling Rig?

The warranty period for new machine is 1 year or 2000 working hours, whichever comes first will be applied.

Please contact with us for detailed Warranty Regulation.

Q2: What's your service ?

We can offer professional technical support and good after-sale service to you.

Modification methods will be different according to different models and configurations of your owned excavators.

Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.

Before modifying, you need to confirm technical specification.
