Customized NT100X Removable Heat Exchanger Plate for GEA Multi Material
Customized NT100X Removable Heat Exchanger Plate for GEA Multi Material
Customized NT100X Removable Heat Exchanger Plate for GEA Multi Material
Customized NT100X Removable Heat Exchanger Plate for GEA Multi Material
Customized NT100X Removable Heat Exchanger Plate for GEA Multi Material
Customized NT100X Removable Heat Exchanger Plate for GEA Multi Material
Customized NT100X Removable Heat Exchanger Plate for GEA Multi Material
Customized NT100X Removable Heat Exchanger Plate for GEA Multi Material
Customized NT100X Removable Heat Exchanger Plate for GEA Multi Material
Customized NT100X Removable Heat Exchanger Plate for GEA Multi Material
Specifications
Brand Name :
GEA Series
Certification :
IOS/SGS
Place of Origin :
Qingdao,China
MOQ :
100PCs
Price :
$4.5
Payment Terms :
L/C,T/T,Western Union,MoneyGram
Supply Ability :
5000/Week
Delivery Time :
5-7Days
Packaging Details :
BOX/Pallet/Wooden Box
Plate Embossing :
Chevron or diamond pattern
Color :
Silver
Thickness :
0.5mm, 0.6mm
Material Quality :
Food Grade
Max Working Temperature :
150°C
Model :
TS20
Warranty :
1 Year
Design Function :
Channel Plate
Sectional Shape :
Corrugation
Plate Type :
Gasketed Plate
Temperature :
Up To 180°C
Plate Arrangement :
Parallel Flow
Plate Pattern :
Herringbone
Machinery Test Report :
Provided
Description

Our NT100X plate is a precision interchangeable spare part designed for GEA removable plate heat exchangers. It delivers stable heat transfer, strong corrosion resistance, and perfect fit for industrial heating, cooling, and heat recovery systems.

Customized NT100X Removable Heat Exchanger Plate for GEA Multi Material

Key Product Features
  • 100% interchangeable with original GEA NT100X units
  • Multi-material available: SS304, SS316L, Titanium, Ti-Pd, 254SMO, SS904L
  • High-precision stamping & forming, consistent dimension
  • 128° herringbone design for high turbulence & high efficiency
  • Low pressure loss, long service life, easy cleaning & maintenance
  • Compatible with food, chemical, seawater, HVAC, oil & gas applications
Material Selection Guide
  • SS304: Clean water, light oil, general industry
  • SS316L: Weak corrosion, food & beverage, cooling systems
  • Titanium / Ti‑Pd: Seawater, brine, high chloride environment
  • 254SMO / SS904L: Strong corrosion, chemical, acid, harsh working conditions
Technical Parameters (NT100X)
  • Model: NT100X
  • Plate angle: 128°
  • Port size: φ110
  • Plate size: 1519×262 mm
  • Overall size: 1709×445 mm
  • Heat transfer area: 0.63 m² per plate
  • Thickness: 0.5–1.0 mm optional
  • Design pressure: up to 2.0 MPa
Applications
  • HVAC & district heating
  • Food & beverage: milk, beer, juice, pasteurization
  • Chemical process, oil cooling
  • Seawater desalination, salt water treatment
  • Industrial waste heat recovery
Why Choose Us
  • Perfect Interchange: Match original GEA dimensions, no installation issues
  • Full Material Range: Cover all common and high-corrosion working conditions
  • Strict Quality Control: ISO certified, pressure test, dimension inspection
  • Fast Delivery: Ready molds, short lead time for samples and bulk
  • Global Service: Export worldwide, technical support for selection & installation
  • Cost-Effective: High quality at competitive price, lower your maintenance cost
FAQ
1. Is this NT100X plate compatible with my GEA heat exchanger?

Yes, it is fully interchangeable with original GEA NT100X plates, same dimensions and performance.

2. What materials can I choose?

We supply SS304, SS316L, Titanium, Ti-Pd, 254SMO, SS904L to match different corrosive media.

3. What thickness do you offer?

Standard 0.5/0.6/0.7/0.8/1.0 mm, customizable on request.

4. What is your MOQ and lead time?

MOQ: 1 piece; sample orders welcome. Bulk lead time: 7–15 working days.

5. Do you provide gaskets for NT100X?

Yes, we supply matching NBR, EPDM, HNBR, Viton gaskets for NT100X.

6. Can you customize logo or package?

Yes, OEM & ODM services are supported.
