3KM Range X-band high-precision three coordinate low altitude defense radar tracking system
3KM Range X-band high-precision three coordinate low altitude defense radar tracking system
3KM Range X-band high-precision three coordinate low altitude defense radar tracking system
3KM Range X-band high-precision three coordinate low altitude defense radar tracking system
3KM Range X-band high-precision three coordinate low altitude defense radar tracking system
3KM Range X-band high-precision three coordinate low altitude defense radar tracking system
Specifications
Brand Name :
Lei Kan
Model Number :
LKYF-R02A
MOQ :
1
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Flexible Multi-Mode Switching :
Supports TWS, STT, and other tracking modes
Power Consumption :
≤ 220 W
Detection Range :
(Mavic 2 / Phantom 4) ≥ 2.5 km / ≥ 3 km
Electromagnetic Silence Control :
Supports sector silence settings
Description

Ⅰ. Product Overview

The Low altitude defense radar tracking system is a three-coordinate radar system based on the Pulse-Doppler principle. It employs a hybrid scanning mode, combining mechanical scanning in azimuth with phase scanning in elevation, and is designed for detecting and locating low-altitude aerial vehicles. The radar provides high-precision spatial target localization and can be integrated with various countermeasure systems, such as electro-optical (EO) systems, jamming equipment, laser weapons, and navigation spoofing devices, to form a unified defense solution.

3KM Range X-band high-precision three coordinate low altitude defense radar tracking system

Ⅱ. Product Core Capabilities

1. Detection and tracking of various moving targets, with data output on position, velocity, and type.

2. Features target classification and identification capabilities.

3. Supports multiple operational modes: Track While Scan (TWS) and Single Target Track (STT).

4. Capable of on-the-move operation (platform positioning, orientation, and time synchronization supported).

5. Supports automated calibration (for position, orientation, and attitude).

6. Allows for sector-based electromagnetic silence settings.

7. Can maintain stable tracking of hovering targets.

8. Equipped with active/passive anti-jamming capabilities.

9. Features built-in self-test and system health assessment functions.

3KM Range X-band high-precision three coordinate low altitude defense radar tracking system

3KM Range X-band high-precision three coordinate low altitude defense radar tracking system



Ⅲ. Product Technical Specifications

Item

Specification

Operating Band

X-Band (9 ~ 10.2 GHz)

Detection Range (DJI Mavic 2 Equivalent)

≥ 2.5 km

Detection Range (DJI Phantom 4 Equivalent)

≥ 3 km

Accuracy (Azimuth/Elevation/Range)

≤ 0.6° / ≤ 0.6° / ≤ 10 m

Speed Measurement Range

1 ~ 100 m/s

Blind Zone

≤ 150 m

Elevation Coverage

0° ~ 40°

Overall Dimensions (L x W x H)

≤ 885 x 330 x 570 mm

Total Weight

≤ 35 kg

Power Consumption

≤ 220 W

Operating Temperature

-40℃ ~ +65℃

Storage Temperature

-50℃ ~ +65℃

Ingress Protection Rating

IP65


3KM Range X-band high-precision three coordinate low altitude defense radar tracking system



Ⅳ. Company Presentation

3KM Range X-band high-precision three coordinate low altitude defense radar tracking system





Ⅴ. Service Support

3KM Range X-band high-precision three coordinate low altitude defense radar tracking system
