Specifications
Brand Name :
CHONGYANG
Model Number :
CY-PWS-1000LPH
Certification :
ISO
Place of Origin :
China
MOQ :
10
Price :
USD 100--1000
Payment Terms :
L/C, T/T
Supply Ability :
100 Sets/Month
Delivery Time :
With 30-40 Days
Packaging Details :
According to export standard
capacity :
250LPH-50000LPH
Conductivity :
≤1.3 μS/cm
TOC :
≤500 ppb
Microbial Limit :
≤100 CFU/ml
Recovery Rate :
≥97%
RO Configuration :
Double Pass RO
EDI Module :
High Temperature, Normal Temperature type
RO Membrane :
4040 / 8040
RO Housing :
SS304/SS316l
System Material :
SS304 / SS316L
Pipe Material :
SS316L Electropolish
Surface Finish :
Ra ≤0.6 μm
Description


Pharma PW System With UV Sterilization Module

A pharma PW system with UV sterilization module is designed to provide stable purified water for clean utility applications in biotechnology, healthcare, laboratory, and pharma-related industries.

The system is suitable for process water preparation, equipment rinsing, clean circulation loops, hygiene-sensitive production, and controlled water storage.

What Is a Pharma PW System With UV Sterilization Module?

A pharma PW system with UV sterilization module is a complete purified water generation and distribution solution designed for industries that require reliable low-conductivity water and hygienic circulation.

The system normally combines pretreatment, reverse osmosis, optional EDI polishing, UV sterilization, sanitary storage, and a controlled distribution loop.

The UV module uses ultraviolet light, usually at 254 nm, to reduce microbial load in the water stream without adding chemicals into the water.

Technical Specifications

Item Standard Configuration
Product Name Pharma PW System With UV Sterilization Module
Production Capacity 500 L/h – 30,000 L/h
Main Process Pretreatment + RO + UV + Storage + Distribution Loop
UV Module 254 nm UV Sterilization
RO Configuration Single Pass RO / Double Pass RO
Water Quality Low Conductivity Purified Water
Main Material SS304 / SS316L
Control System PLC + HMI Touch Screen
Specific production capacity can be customized according to raw water quality, flow demand, installation space, and final water quality requirements.

Features & Advantages

Integrated UV Module

Helps reduce microbial load and supports stable purified water quality.

Stable PW Generation

Combines pretreatment and RO technology for reliable clean utility water.

No Chemical Addition

UV treatment works without adding chemical agents into the water.

Hygienic Loop Design

Continuous circulation helps reduce stagnant water and improve system stability.

Automatic Operation

PLC control supports alarms, monitoring, and easy system management.

Skid-Mounted Structure

Modular design simplifies installation, transportation, and commissioning.

Flexible Configuration

RO, EDI, UV, ozone, hot water, and storage systems can be customized.

Long-Term Operation

Stable pumps, sanitary piping, and practical maintenance access support daily use.

Application Industries

Biotechnology Industry

Used for clean utility water generation and controlled production environments.

Healthcare Industry

Suitable for equipment cleaning, hygiene-sensitive water use, and controlled utility systems.

Laboratory & Research Centers

Provides stable purified water for testing, sample preparation, and research environments.

IVD Industry

Suitable for reagent preparation, equipment cleaning, and controlled water applications.

Medical Device Industry

Used for precision equipment cleaning, component rinsing, and clean production environments.

Biopharma Industry

Applicable for biological production, formulation preparation, and clean utility systems.

Production Process

The following process flow shows a typical PW system with UV sterilization module.

Raw Water
→
Sand Filter
→
Carbon Filter
→
Softener
→
Security Filter
→
RO System
→
UV Module
→
Sanitary Tank
→
Distribution Loop
→
Point of Use

Optional Configurations

  • Double Pass RO System
  • EDI Polishing Unit
  • Ozone Sanitization System
  • Hot Water Sanitization System
  • Online Conductivity Monitoring
  • Online TOC Monitoring
  • SS316L Sanitary Storage Tank
  • SS316L Electropolished Piping
  • Automatic CIP System
  • UV Intensity Monitoring
  • Modular Skid-Mounted Frame
  • Distribution Circulation Loop

Why Choose CHONGYANG WATER

CHONGYANG WATER is a professional manufacturer of purified water generation systems, RO water treatment systems, UV sterilization water systems, and clean utility engineering solutions.

  • Professional water treatment engineering team
  • Experience in RO, EDI, UV, ozone, and sanitary loop systems
  • Customized purified water system design
  • Skid-mounted engineering capability
  • Factory-direct manufacturing and quality control
  • FAT and SAT support
  • Installation and commissioning guidance
  • Long-term after-sales technical support

Request a Customized Solution

Looking for a reliable pharma PW system with UV sterilization module?

CHONGYANG WATER provides customized purified water generation systems for biotechnology, healthcare, laboratory, and clean utility water applications.
