Automatic 16 Passageway Capsule Counting Machine 40-60 Bottles/Min
Automatic 16 Passageway Capsule Counting Machine 40-60 Bottles/Min
Specifications
Brand Name :
SED Pharma
Model Number :
SED-16S
Certification :
CE
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T,L/C,,Cash
Supply Ability :
30 Sets Per Month
Delivery Time :
35 days after receiving the deposit
Packaging Details :
Wooden Case
Name :
Automatic 16 Passageway Soft Capsule Counting Machine Convenient Maintenance
Model :
SED-16
Applicable bottle shape :
10-500ml round,square plastic bottle
Production capacity :
40~60 bottles per minute(It depends on the bottle size,filling quantity and the tablet size)
The setting range of bottling volume :
2-9999
Power supply :
AC220V 50Hz 0.6kw
Accuracy rate :
>99.5%(better than the industrial standard )
Air Source :
0.6 Mpa
material :
stainless steel
key word :
Capsule Counting Machine Tablet bottling machine
Description
Automatic 16 Passageway Tablet Gummy Pill Counter Small Capsule Packing Counting Machine
Product Description
This counting machine is designed for accurately counting capsules, soft gels, tablets, chewing gum, round pills, and other solid materials. The contact parts are made of superior 304 stainless steel, meeting GMP requirements. The bottle blocking device on the conveyor belt positions bottles for filling, while material is fed through vibration and counted by photoelectric sensors before being loaded into bottles.
Technical Parameters
Model Name SED-16S
Application
  • Hard capsule (000-5#)
  • Soft Gelatin capsule
  • Pills
  • Chewing gum, tablet, other solid object (Diameter: 5.5-22mm)
Hopper Volume 70L
Capacity 10-70 bottles/min
Filling Quantity 2-9999pcs/bottle (adjustable)
Bottle Size Diameter ≤50mm, Height ≤180mm
Conveyor Belt Width 114mm
Compressed Air 0.6Mpa, 3.8L/min
Voltage 220V, 50HZ Single Phase
Power 0.9KW
Weight 480kg
Overall Dimension (L*W*H) 1560*1530*1700mm
Key Features
  • 3-stage adjustable vibrating platform for precise speed control of capsule count output
  • Strong compatibility with tablets (including special-shaped), capsules, soft capsules, and pills
  • 16-channel vibration discharge system for smooth, damage-free material handling
  • Anti-dust photoelectric sensor technology for stable operation in high dust conditions
  • High accuracy counting with photoelectric sensor technology
  • Intelligent operation with multiple detection alarm control functions
  • Automatic detection for tilted bottles and bottle jams
  • User-friendly touch screen interface
  • No mold changes required when switching counting objects
Machine Display
Automatic 16 Passageway Capsule Counting Machine 40-60 Bottles/Min
Applications
This machine is designed for counting and packing solid particles including tablets, capsules (transparent or non-transparent hard capsules, soft capsules), and pills (3-20mm wide) into bottles, boxes, and bags. It meets GMP requirements and is suitable for research institutions, hospitals, small and medium-sized enterprises, and healthcare product plants.
Automatic 16 Passageway Capsule Counting Machine 40-60 Bottles/Min
