Automatic Capsule Filling Machine with Touch-Screen and PLC Control for Powder and Pallet Filling CE Certified
Automatic Capsule Filling Machine with Touch-Screen and PLC Control for Powder and Pallet Filling CE Certified
Automatic Capsule Filling Machine with Touch-Screen and PLC Control for Powder and Pallet Filling CE Certified
Automatic Capsule Filling Machine with Touch-Screen and PLC Control for Powder and Pallet Filling CE Certified
Specifications
Brand Name :
SED-pharma
Model Number :
SED-200J-H
Certification :
CE
Place of Origin :
Zhejiang, China
MOQ :
>=1 Pieces
Payment Terms :
T/T,L/C,MoneyGram,Cash
Supply Ability :
30 Piece/Pieces per Month
Delivery Time :
Est. Time(days)-15-To be negotiated
Packaging Details :
Export standard packing
Name :
Automatic Capsule Filling Machine for Pharma Health Product
Capacity :
200 capsules/min
Power Consumption :
3.75Kw
Material :
stainless steel
Filling type :
Powder, Pallet
No. of Dose/holes of each mold :
2
Suitable for Capsule :
00#, 0#, 1#, 2#, 3#, 4#
key word :
Powder Capsule Filling Machine Automatic Capsule Filling Machine
Description

Product Description of Capsule Filling Machine
A fully automatic capsule filling machine is a professional capsule filling equipment, mainly used in pharmaceuticals, health products, hospital preparation rooms and other industries.

It adopts hole-type filling, intermittent operation, etc., which can automatically complete the filling and dividing of capsules. , filling, (waste capsule removal) locking capsules, finished product output, and other processes are not only safe, hygienic, and reliable, but also have high precision, strong sealing, low noise, and high output, meeting the needs of modern production.


Product Parameters of Capsule Filling Machine

Model No.

SED-200J-H

Capacity

200 capsules/min

Filling type

Powder, Pallet

No. of Dose/holes of each mold

2

Suitable for Capsule

00#, 0#, 1#, 2#, 3#, 4#

Filling error

±3%-±4%

Noise

≤75dB(A)

Voltage

380V 50Hz 3P

Total Power

3.75Kw

Overall Weight

600Kg

Gross Weight

650Kg

Machine Dimension

750mm. (L) x 680mm(W) x 1700mm(H)

Packing Dimension

1600mm. (L) x 1050mm(W) x 1900mm(H)




Features of the Capsule Filling Machine

² Touch-Screen, PLC program control panel with LCD.

² Capsule vacuum positioned mechanism to make the capsule qualified over 99%.

² Removable powder hopper for cleaning and easy auger adjustment, easy to change fill weights.

² Easy speed selection and closed capsule length adjustment.

² Electrical Appliance control system approved to CE and international standards.

² Quick and accurate change part set-up, easy to remove the rotary table and ring carrier assembly.

² Fully enclosed dosing stations and rotating table for integration of the whole capsule filling plants.

² Large cam mechanism keeps the rotating table of the mold together with the whole equipment running in

² balance, and completely guarantees the machine operating with the highest precision and accuracy.



Application of the Capsule Filling Machine

The automatic capsule filling machine is mainly used for filling powder or pellet capsule medicines in medicine, hospital preparation room, health care products and other industries.
