Specifications
Brand Name :
LTPM CHINA
Model Number :
HorizonTop--Series
Certification :
CE,ISO
Place of Origin :
Zhejiang，China
MOQ :
1 Set
Price :
Consultation and detailed discussion
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
25sets/month
Delivery Time :
35days
Packaging Details :
Export Standard Wooden Case
Packaging type :
Stand-up Pouch, Bags, Film, Pouch, Sealing
Automatic grade :
Automatic
Voltage :
380 V/220V
Filling Material :
Powder, Paste, Granule, Liquid, Solid
Application :
Food,Beverage,Commodity,Chemical,Machinery & Hardware,Apparel,Textiles,Cigarettes,Pharmaceutical
Warranty :
5 years
Description

Products Description

This corner spout doypack packing machine is suitable for filling packing different liquid, paste and cream
products such as water, oil, milk, juice, ketchup, tomato, sauce, peanut butter, honey, mayonnaise, liquid
detergent, shampoo, body washing and other non free-flowing liquid when equipped with different filling
machines like Piston Pump Filling, Peristaltic Pump Filling, Haibar Pump Filling. With the suitable filling
solution to meet the filling accuracy and packing speed requirements and avoid the liquid material bubble,
forming, dripping, and splashing. The horizontal pouch packaging machine is a fully-automatic packing machine,
which is widely used for food / beverage/cosmetics/chemicals/pharmaceuticals packaging.
Roll Film Standup Pouch Top Spout Doypack Milk Tea Filling Horizontal multifunctional packaging machine
Machine Data
Model
HorizonTop--210
HorizonTop--250
HorizonTop--360
HorizonTop--450
HorizonTop--500
Speed
30-50 bags/min
30-45 bags/min
15-35 bags/min
40-80 bags/min
3-15 bags/min
Accuracy
± 1.5%
± 1.5%
± 1.5%
± 1.5%
± 1.5%
Bag width
55-200mm
80-250mm
120-350mm
100~200mm
120-400mm
Bag height
100-280mm
100-280mm
100-280mm
100~280mm
150-500mm
capacity
1-5kg
1-5kg
1-5kg
1-5kg
1-15kg
Power
4kw
4kw
4kw
6kw
4kw
Gas consumption
0.6m3/min
0.6m3/min
0.6m3/min
0.6m3/min
0.6m3/min
Air pressure value
0.6MPa
0.6MPa
0.6MPa
0.6MPa
0.6MPa
Weight
1450kg
1700kg
2200kg
2000kg
800kg
Size(mm)
2900*1000*1390
3500*1000*1390
3900*1000*1390
3800*1000*1200
2300*1000*1390
Warranty
5 years
5 years
5 years
5 years
5 years

Roll Film Standup Pouch Top Spout Doypack Milk Tea Filling Horizontal multifunctional packaging machine

1. Film Unwind 2..Pouch Forming 3.Film Guide 4.Bottom Seal 5.Vertical Seal I 6.Tear Notch 7.Photocell 8.Duplex Cutting 9.Duplex Pouch Catching 10.Advance 11.Pouch Opening 12.Filling 13.Vibrator 14.Spout Adding 15. Spout Inserting 16.Finished Product 17.Output

Roll Film Standup Pouch Top Spout Doypack Milk Tea Filling Horizontal multifunctional packaging machine

Focus On Details

Roll Film Standup Pouch Top Spout Doypack Milk Tea Filling Horizontal multifunctional packaging machine
Light Walking Beam
1. Faster working speed
2. Longer operational life span
Roll Film Standup Pouch Top Spout Doypack Milk Tea Filling Horizontal multifunctional packaging machine
Servo Advance system
1. Easy computerized specificatiorchange
2. Stable pouch advance withless deviation
3. Big torquemoment of pouchadvance, suitable for big volume
Roll Film Standup Pouch Top Spout Doypack Milk Tea Filling Horizontal multifunctional packaging machine
Dual Filling Station
1. Reduce filling time by half
2.lmproved filling accuracy
3. Can filling 2 products simultaneously
