Vertical Type Pharmaceutical Processing Machines Semi Automatic Cartoning Machine
Vertical Type Pharmaceutical Processing Machines Semi Automatic Cartoning Machine
Vertical Type Pharmaceutical Processing Machines Semi Automatic Cartoning Machine
Vertical Type Pharmaceutical Processing Machines Semi Automatic Cartoning Machine
Vertical Type Pharmaceutical Processing Machines Semi Automatic Cartoning Machine
Vertical Type Pharmaceutical Processing Machines Semi Automatic Cartoning Machine
Vertical Type Pharmaceutical Processing Machines Semi Automatic Cartoning Machine
Vertical Type Pharmaceutical Processing Machines Semi Automatic Cartoning Machine
Vertical Type Pharmaceutical Processing Machines Semi Automatic Cartoning Machine
Vertical Type Pharmaceutical Processing Machines Semi Automatic Cartoning Machine
Specifications
Brand Name :
LEADTOP
Model Number :
ZH-50
Certification :
CE.ISO
Place of Origin :
China
MOQ :
1set
Price :
USD12000-15000 per set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
30days
Packaging Details :
standard export wooden case packing
Product name :
semi automatic cartoning machine
usage :
blister tube sachet bottle cartoning
Packing speed :
20-50cartons per min
Dimension :
1100*1500*1900MM
Weight :
450Kg
warranty :
1 year
Air pressure :
0.5-0.8Mpa
driven type :
Electric
Feature :
Easy Operation
Model :
ZH-50
power supply :
220V 50HZ single phase
Description

Vertical Type Pharmaceutical Processing Machines Semi Automatic Cartoning Machine

Application:

  • Round bottled medicine, food-stuff, cosmetic, etc. packing into square box.

Feature:

  • It is specially design to pack small quantities multi size box.
  • With low cost and only require small area. It is suitable for various sizes of box. The machine is a vertical type with multiple function and require a short time to change mould.
  • 304 stainless steel case
  • Advanced PLC Control System Combined with 5.7” Colorful Touch Screen Control Panel , can easily set and change the packing parameters.

Main Technical Data

Model ZH-50
Packing speed 20-50 Cartons/min
Carton size range L(40-125)mm×W(12-80)mm×H(12-80)mm
Carton gram requirements 250-350g/m3
Motor power 1.5KW
Power supply Three phase 380V 50Hz
Machine noise ≤80dB
Air pressure 0.5-0.8 Mpa
Air consumption 150L/min
Dimension 1100×1500×1900 mm
Weight 250Kg

Different products we packed:

Vertical Type Pharmaceutical Processing Machines Semi Automatic Cartoning Machine
