Solvent-Free Fast-Curing Epoxy Primer for Heat Shrink Sleeve Systems with Excellent Cathodic Disbondment Resistance
Solvent-Free Fast-Curing Epoxy Primer for Heat Shrink Sleeve Systems with Excellent Cathodic Disbondment Resistance
Solvent-Free Fast-Curing Epoxy Primer for Heat Shrink Sleeve Systems with Excellent Cathodic Disbondment Resistance
Solvent-Free Fast-Curing Epoxy Primer for Heat Shrink Sleeve Systems with Excellent Cathodic Disbondment Resistance
Solvent-Free Fast-Curing Epoxy Primer for Heat Shrink Sleeve Systems with Excellent Cathodic Disbondment Resistance
Solvent-Free Fast-Curing Epoxy Primer for Heat Shrink Sleeve Systems with Excellent Cathodic Disbondment Resistance
Solvent-Free Fast-Curing Epoxy Primer for Heat Shrink Sleeve Systems with Excellent Cathodic Disbondment Resistance
Solvent-Free Fast-Curing Epoxy Primer for Heat Shrink Sleeve Systems with Excellent Cathodic Disbondment Resistance
Solvent-Free Fast-Curing Epoxy Primer for Heat Shrink Sleeve Systems with Excellent Cathodic Disbondment Resistance
Solvent-Free Fast-Curing Epoxy Primer for Heat Shrink Sleeve Systems with Excellent Cathodic Disbondment Resistance
Specifications
Flame Retardant :
Yes
Temperature Resistance :
-30℃ to 80℃
MOQ :
500 PCS
Corrosion Resistance :
Excellent
Brand Name :
CNPetro
Certification :
ISO
Delivery Time :
8 work days
Payment Terms :
L/C,T/T
Recommended Thickness :
150-500 μm
Model Number :
HTLP 60
Price :
USD 20
Place of Origin :
China
Supply Ability :
5000 sets/week
Water Proof :
Yes
Packaging Details :
400*400*420mm
Impact Resistance :
≥15J
Description

Epoxy Primer A &B for Heat Shrink Sleeve Systems

Product Introduction

Our two-component epoxy primer is specifically formulated as the first layer of a three-layer heat shrink sleeve system for pipeline field joint corrosion protection. The solvent-free epoxy composition provides a high-build, fast-curing base that bonds firmly to blast-cleaned steel and compatible factory coatings, ensuring the shrink sleeve adhesive achieves durable peel strength and superior cathodic disbondment resistance.

Key Characteristics

Aspect Details
Composition Two-component, 100% volume solids (solvent-free) epoxy resin system
Function First layer of three-layer shrink sleeve system; prepares steel surface for adhesive bonding
Key Performance Excellent cathodic disbondment resistance, fast curing, high-build application, strong adhesion to steel and factory coatings
Compatibility PE, PP, FBE, PU, CTE, and bitumen mainline coatings


Application Manual or machine application by hand, roller, or spray; applied to prepared steel surface before sleeve installation
Technical Standards Compliant with ISO 21809-3, EN 12068, DIN 30672, and applicable GB/T standards


Typical Properties

Property Typical Value
Type Two-component, solvent-free
Color Black
Recommended Thickness 150–500 μm
Pot Life (23°C) Approximately 20 minutes
Mixing Ratio Varies by product (e.g., 100:28 or 4:1 by weight/volume)
Curing Heat-assisted curing available for force-cure systems

System Integration

This primer is designed to work as an integrated component of heat shrink sleeve systems, compatible with common field joint coating configurations including three-layer PE and PP systems. When used with compatible shrink sleeves, the complete system meets the requirements for operating temperatures up to 100°C or higher depending on grade. The epoxy layer provides the critical bond between the steel substrate and the shrink sleeve adhesive, forming a durable, watertight corrosion protection structure for pipeline field joints
