15P/Min 25KW PE Film Mineral Water Bottle Packing Machine Leakage Proof
15P/Min 25KW PE Film Mineral Water Bottle Packing Machine Leakage Proof
15P/Min 25KW PE Film Mineral Water Bottle Packing Machine Leakage Proof
15P/Min 25KW PE Film Mineral Water Bottle Packing Machine Leakage Proof
15P/Min 25KW PE Film Mineral Water Bottle Packing Machine Leakage Proof
15P/Min 25KW PE Film Mineral Water Bottle Packing Machine Leakage Proof
15P/Min 25KW PE Film Mineral Water Bottle Packing Machine Leakage Proof
15P/Min 25KW PE Film Mineral Water Bottle Packing Machine Leakage Proof
Specifications
Brand Name :
StepChina/Mingstar
Model Number :
YCD-6535
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
50 sets per year
Delivery Time :
15 working days
Packaging Details :
wooden case
Standard Capacity :
10-15 Pcs/minute
Usage :
Bottled beverage package
Material :
Carbon steel
Suitable flim :
Shrinkable PE film
Air consumption :
0.5 M3/Minute
Power :
380V 50HZ 3 Phase
Total Power :
25KW
Weight :
700Kg
Description

Automatic Beverage Bottle Packing Machine With Shrinkable PE Film 10 - 15pcs/min

Description:

  • It is suitable for wrapping pop-cans, bottles, etc, both with bottom-tray and without bottom-tray, working with PE shrink tunnels.
    The machine adopts advanced technology and international famous brands, which makes capability stable and using long-time.

    1. Up and down magnetic switches prevent sealing mistakes and protect the operators.
    2 The input position is adjustable, base on the size of products packaged.
    3. Schneider AC contractor and Intelligent temperature controller perform stably.
    4. Large power conveyer motor, with step-less speed regulating, ensures smooth feeding.
    5. Up and down large power fan system ensures the excellent effect of shrinking in one time.
    6. Super cooling system cools the packing and makes the figuration perfectly.
    7. The size of the tunnel can be customized as your request.

Quick Detail:

Name Shrinking machine, film packing machine, film shrinking machine, film shrinker


Brand Name


Stepchina/Mingstar


Capacity


10-12 packages/min


Material


Carbon steel


Function


Film cutting, wrapping, shrinking


Usage

 Packing bottled water into plastic package


Applications:

1. bottled water package.
2. bottled beverage plastic packing.


15P/Min 25KW PE Film Mineral Water Bottle Packing Machine Leakage Proof


15P/Min 25KW PE Film Mineral Water Bottle Packing Machine Leakage Proof
Technical Parameters:


Dimension For The Whole Unit


L6500mm×W3200mm×H2100m


Thermal Shrinkage Tunnel Dimension


L1800mm×W650mm×H450mm


Max Package Dimension


L600mm×W400mm×H350m


Packaging Speed


10-15Pcs/minut


Transfer Belt Dimension


304mm


Sealing And Cutting Time/Temperature


0.5-1.5s 140℃-160℃


Work Voltage/Power


3Phase 5Line380V 19KW


Work Air Pressure


0.6-0.8Mpa


Air Consumption


0.5m3/minute


15P/Min 25KW PE Film Mineral Water Bottle Packing Machine Leakage Proof

Competitive Advantage:

  • high quality production
  • high efficiency
  • high precision
  • automatic control
  • reliable electronic elements
