Peltier Plate Cooler 40W for Industrial Devices Medical Diagnostics and Food and Beverage Cooling
Peltier Plate Cooler 40W for Industrial Devices Medical Diagnostics and Food and Beverage Cooling
Peltier Plate Cooler 40W for Industrial Devices Medical Diagnostics and Food and Beverage Cooling
Peltier Plate Cooler 40W for Industrial Devices Medical Diagnostics and Food and Beverage Cooling
Peltier Plate Cooler 40W for Industrial Devices Medical Diagnostics and Food and Beverage Cooling
Peltier Plate Cooler 40W for Industrial Devices Medical Diagnostics and Food and Beverage Cooling
Peltier Plate Cooler 40W for Industrial Devices Medical Diagnostics and Food and Beverage Cooling
Peltier Plate Cooler 40W for Industrial Devices Medical Diagnostics and Food and Beverage Cooling
Peltier Plate Cooler 40W for Industrial Devices Medical Diagnostics and Food and Beverage Cooling
Peltier Plate Cooler 40W for Industrial Devices Medical Diagnostics and Food and Beverage Cooling
Peltier Plate Cooler 40W for Industrial Devices Medical Diagnostics and Food and Beverage Cooling
Peltier Plate Cooler 40W for Industrial Devices Medical Diagnostics and Food and Beverage Cooling
Specifications
Brand Name :
Adcol
Model Number :
ATP040-12VDC
Certification :
ISO9001 , CE
Place of Origin :
China
MOQ :
1EA
Price :
Negotiation
Payment Terms :
T/T , Paypal
Supply Ability :
500pcs per month
Delivery Time :
3 - 4 weeks
Packaging Details :
Solid carton packaging
P/N :
ATP040-12VDC
Cooling Method :
Plate Cool
Radiating method :
Air Force
Ambient temperature/humidity :
-10 to 55°C
Cooling Capacity :
40W
Nominal/Max Voltage :
12/15VDC
Fan, hot side :
92X25mm,12VDC,0.0.24
Weight :
1.0KG
Life Time :
>=70,000 Hours
Noise :
45dB
Tolerance :
10%
Description

40W Air to Plate thermoelectric Cooler Assembly

1.Product Introduction

The ATP040-12 Thermoelectric air plate is designed forelectronic cabinets and environmental

chambers.lt canmaintain ambient temperatures while removing up to 50W.This model is

available in 12VDC configurations. This airColdplate is virtually maintenance-free,

with no filters ambientto change, and it can be mounted in any orientation,

offeringdesign flexibility with solid-state reliability.

Peltier Plate Cooler 40W for Industrial Devices Medical Diagnostics and Food and Beverage Cooling
2.Features
  • 40W capacity rated at ΔT= 0C,Tambient =30°℃
  • Refrigerant free-environmentally friendly
  • Wide operating temperature range of -10°Cto +55℃℃
  • Shift between heating and cooling without using a heater
  • Reduced noise and vibration with no moving parts

3.Application

  • Analytical instrument
  • Medical diagnostics
  • Industrial device
  • Food and Beverage Cooling

4.Design drawing

Peltier Plate Cooler 40W for Industrial Devices Medical Diagnostics and Food and Beverage Cooling

Peltier Plate Cooler 40W for Industrial Devices Medical Diagnostics and Food and Beverage Cooling
