30% Glass Fiber Reinforced Polyetherimide PEI Rod High Temperature Resistance
30% Glass Fiber Reinforced Polyetherimide PEI Rod High Temperature Resistance
30% Glass Fiber Reinforced Polyetherimide PEI Rod High Temperature Resistance
30% Glass Fiber Reinforced Polyetherimide PEI Rod High Temperature Resistance
30% Glass Fiber Reinforced Polyetherimide PEI Rod High Temperature Resistance
30% Glass Fiber Reinforced Polyetherimide PEI Rod High Temperature Resistance
30% Glass Fiber Reinforced Polyetherimide PEI Rod High Temperature Resistance
30% Glass Fiber Reinforced Polyetherimide PEI Rod High Temperature Resistance
30% Glass Fiber Reinforced Polyetherimide PEI Rod High Temperature Resistance
30% Glass Fiber Reinforced Polyetherimide PEI Rod High Temperature Resistance
30% Glass Fiber Reinforced Polyetherimide PEI Rod High Temperature Resistance
30% Glass Fiber Reinforced Polyetherimide PEI Rod High Temperature Resistance
30% Glass Fiber Reinforced Polyetherimide PEI Rod High Temperature Resistance
30% Glass Fiber Reinforced Polyetherimide PEI Rod High Temperature Resistance
30% Glass Fiber Reinforced Polyetherimide PEI Rod High Temperature Resistance
30% Glass Fiber Reinforced Polyetherimide PEI Rod High Temperature Resistance
Specifications
Brand Name :
PRES
Model Number :
P-2300R
Certification :
ROHS REACH
Place of Origin :
China
MOQ :
1kg
Price :
25USD/kg
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
250Tones per month
Delivery Time :
5-8 working days
Packaging Details :
25kgs/bag
Material :
30% glass fiber filled polyetherimide
Density :
1.51g/cm³
Tensile Stress, yld, Type I, 5 mm/min :
151Mpa
Tensile Strain, brk, Type I, 5 mm/min :
2.4%
Tensile Modulus, 1 mm/min :
10500
Flexural Stress, break, 2 mm/min :
240 Mpa
Flexural Modulus, 2 mm/min :
9600
Hardness, Rockwell M :
110
Description

30%glass fiber reinforced high temperature resistance PEI rod

High load high temperature resistance insulation Material:

Glass fiber reinforced PEI material is a structural material with high temperature resistance and high load-bearing capacity and insulation .

PEI resin material Thermal deformation temperature(HDT) is 200°C,Compared with PEI GF30 HDT (215°C),Better resistance to creep under high temperatures

His insulation property will not show a significant decline due to temperature changes, and his electrical performance will not deteriorate when transitioning from low frequencies to high frequencies.


In addition to its excellent electrical performance, its reliability at high temperatures is also very impressive.


After reinforced by glass fibers, it can withstand higher weight at high temperatures without significant deformation. Ordinary engineering plastics will expand significantly as the temperature rises. The thermal expansion coefficient of PEI resin is very small , and with the reinforcement of glass fibers, it can be much lower. Its dimensional stability at high temperatures is extremely outstanding.

Other performance:

Natural flame retardancy
Low smoke combustion property
Ultraviolet protectionHigh strength and high rigidity

APPLICATION:

Based on the characteristics of 30% GLASS fiber reinforced PEI, it is suitable for manufacturing high-temperature-resistant, high-load-bearing, dimensionally-stable and high-precision structural components.
