Specifications
Brand Name :
MobyData
Model Number :
M52 Temperature measurement
Certification :
China Certification, CE
Place of Origin :
China
MOQ :
1pcs
Price :
TBD
Payment Terms :
T/T
Supply Ability :
20K pcs per Month
Delivery Time :
7wks days < MOQ500
Packaging Details :
Carton
OS :
Android 9
CPU :
Octa Core, 12nm, 2.0GHz
MEMORY :
RAM: 1GB/2GB Flash: 8GB/16GB
Weight :
174g
Dimension :
155mm x 58mm x 24.5mm
LCD :
2.8 inch, IPS, QVGA 320*240 Visible under sunshine
Sensor :
Gravity sensor, status lamp Temperature sensor
Camera (option version) :
Auto focus 8Mega, with flash LED
Description

Authorized decoding libraries by Datalogic

Application Area

Temperature Measurement PDA Barcode Scanner Android Mobile Computer IP65

Compact commercial PDA device

  • A new generation of ultra-thin image decoding engine, ultra-thin and compact body
  • High specification industrial protection 1.2m 18 falls, 300 0.5m reversals
  • IP65 waterproof and dustproof rating
  • Medical grade temperature sensor chip, ultra-high precision, industrial grade temperature measurement is safe and reliable
  • RFID's excellent reading performance and receiver sensitivity enable high reading accuracy and ultra-long distance tag reading
  • Mobydata software service is supported

Optional Accessory

Temperature Measurement PDA Barcode Scanner Android Mobile Computer IP65

Product specification

M52 Specifications
OS Android 9
CPU Quad Core, 2GHz, 12nm
MEMORY 1+8/2+16
SIM/eSIM nano SIM
eSIM(option version)
PC Communication USB 2.0 OTG : Type-C;Support TYPE-C Headset
Charging Time <3 hours(Room Temperature)
Operation Duration 12 hours
Data Collection
Scan Engine Mobydata E3200/E3250
NFC(2.0 version) 13.56MHz NFC
Temperature Measurement(specific version) Melexis MLX9061 (Medical-grade)
±0.2°C error
RFID(RFID version) 1m to 3m distance
independent 2000mAh battery
Wireless Connectivity
WLAN 802.11 ac/a/b/g/n
WWAN TDD-LTE (B38/B39/B40/B41)
FDD-LTE (B1/B3/B7/B8/B20)
UMTS/HSDPA/HSPA/HSPA+ (900/2100 MHz)
GSM/EDGE/GPRS (900/1800MHz)
WPAN BT 5/BLE
GPS GPS/A-GPS, GLONASS, Beidou, Galileo
Physical Specifications
LCD 2.8 inch, QVGA,IPS
Touch GFF Captive Touch, Dragontrail Glass
Camera(2.0 version) Auto focus 8Mega, with flash LED
Keypad 0-9 Numeric Key, Mode Switch Key, Direction Key, Scan Key
Left and right Scan Key, Power Key
Speaker Min 90db at 10cm-1KHz Voice
Charging IO USB type-C
Charge Pads
Battery 2700mAh, non-removable
4500-4700mAh, non-removable, RFID version
Dimension 155mm x 58mm x17mm
Weight 170g
LED Yes
Vibrator Yes
Handstrap Yes
Environmental Specifications
Operation Temperature -20°C ~ +50°C
Storage Temperature -30°C ~ +70°C
Humidity 10% ~ 90%
Drop 1.2m
Tumble 300hits, 0.5m, Steel
IP IP65
ESD ±8kV Contact, ±15kV Air
Keypad lifecycle 300K
Accessories
Rubber Boot Yes
Charging Cradle Support independent device or RFID charging
Handstrap Nylon
Gift Box
Gift Box Device, QSG, Adapter, USB cable, Rubber Boot

FAQ
1. Are you a manufacturer?
Yes, we are. As a professional manufacturer specializing in barcode scanners and PDA terminals, we possess deep expertise in industrial design, mainboard development, product testing, and full-scale production. We enforce rigorous quality control across all operational processes, ensuring our products consistently meet the highest industry standards.


2. Will you provide free SDK for me?
Certainly


3. What is the warranty period for your products?
Our products come with a Min. 12-month warranty (starting from the date of shipment), excluding parts that are consumable.


4. What is your minimum order quantity (MOQ)?
The standard MOQ for stock products is 1 unit. For OEM/ODM projects, please provide your detailed requirements (e.g., customization scope, specifications), and we will advise the corresponding MOQ based on your needs.


5. Is it possible to obtain a free sample?
While we do not offer free samples, we welcome you to purchase a single sample unit for testing and evaluation.


6. Do you accept payments via PayPal?
No


7. How long is the delivery time?
For sample orders, we usually dispatch within 2-3 working days after payment has been confirmed. For bulk orders, the lead time may vary from 1 to 4 weeks, depending on the exact quantity required.


8. What shipping methods do you use for delivery?
DHL, UPS, TNT, FEDEX, Aramex, EMS, and E-packing, or arrange the collection of goods yourself.

9. Could you describe your after-sales service?
a. All products come with a minimum 12-month warranty (extendable for certain

components), covering manufacturing defects and non-consumable parts.

b. We maintain a large inventory of genuine spare parts to ensure prompt replacement or repair of service requests, minimizing downtime for your operations.

c. Our team of certified engineers provides 24/7 online support (via phone, email, or remote access) to address troubleshooting, software updates, and operational guidance.

d. For complex issues, we can offer on-site service support (subject to regional availability) and customized maintenance plans to meet your specific needs.
