5.08mm Screw PCB Terminal Block 300V 10A Brass Green Euro Type Raising Series
5.08mm Screw PCB Terminal Block 300V 10A Brass Green Euro Type Raising Series
5.08mm Screw PCB Terminal Block 300V 10A Brass Green Euro Type Raising Series
5.08mm Screw PCB Terminal Block 300V 10A Brass Green Euro Type Raising Series
Specifications
Brand Name :
SCED
Model Number :
TJ508-17
Certification :
CE,UL
Place of Origin :
China
MOQ :
500 Piece/Pieces
Price :
USD 0.05-0.12 Per Pole
Payment Terms :
L/C, T/T
Supply Ability :
1000000 Pole/Poles per Month
Delivery Time :
5-10 working days
Packaging Details :
Standard Master Carton Dimension: 341 x 273 x 198mm; Standard Inner box dimension: 168 x 134 x 47mm.
Color :
Green
Pitch :
5.08mm
Current :
10A
Voltage :
300V
Poles :
Any poles available
Screw :
M3
Torque :
4.4-5.4 lbf.in
Insulation Material :
PA66
Inflammability Class :
UL94-V0
Stripping Length :
6-7mm
Description

5.08mm PCB Terminal Block 300V 10A Brass Green Euro Type Raising Series

Detailed product Description:

Pitch 5.08mm, 300V 10A, 2P-24P, PCB Terminal blocks, PCB screw terminal blocks, Euro type Raising series

Wire Inlet: ■Right angle wire inlet; □Vertical wire inlet; □45 degree wire inlet

Levels:■Single Deck; □Double decks; □Triple decks

Standard color: Green.

Other colors are also available, please refer to below How to Order and select the color you want.

How to order:

5.08mm Screw PCB Terminal Block 300V 10A Brass Green Euro Type Raising Series

Competitive Advantage:

  1. More than 1000 models for selection
  2. Good stable quality
  3. CE,UL,CUL,CQC,VDE etc.safety certifications
  4. more than 13 years of experience in designing, manufacturing and marketing

Parameter and Drawing Specifications:

UL Technical Data B C D
Rated Voltage / Current V/A 300/10 300/10
Wire Range AWG 12-26 12-26
IEC Technical Data
Overvoltage Category Ⅲ Ⅲ Ⅱ
Contamination Class 3 2 2
Rated Voltage / Current V/A 250 / 10 400 / 10 630 / 10
Rated Surge Voltage KV 4 4 4
Rated Connecting Capacity mm2 2.5
Material
Insulation Material / Inflammability Class PA66 / UL94, V-0
Clamp Cage / Plating Brass / Nickel Plated
Terminal / Plating Brass / Tin Plated
Screw / Plating Steel / Zinc Plated
Other Data
PCB Hole Diameter mm φ1.5
Stripping Length mm 6-7
Screw / Torque / lbf.in M3 / 4.4-5.3

Applications:

Our terminal blocks can be used in a lot of fields and industries. Such as:

1. Communication, Electrical equipments, Electric Lighting, Security

2. Power Supply, PCB, Rail Transportation, Medical Equipment

3. Military, Automation, Industrial Control, Frequency Converters, Server Site etc.

5.08mm Screw PCB Terminal Block 300V 10A Brass Green Euro Type Raising Series
