Custom Made PCB Boards with Gerber File

♦ What is a Gerber File?​

A ​​Gerber file​​ is the standard file format used in PCB (Printed Circuit Board) manufacturing to describe the physical layers of a PCB design. It contains all the necessary information for fabricating the PCB, including:

    • ​​Copper traces​​
    • ​​Solder mask​​
    • ​​Silkscreen (component labels)​​
    • ​​Drill holes​​

Each layer of the PCB is represented as a separate Gerber file (e.g., .gbr or .ger extension).

Custom PCB Boards Assembly Services Manufacturing With Gerber File Custom PCB Boards Assembly Services Manufacturing With Gerber File Custom PCB Boards Assembly Services Manufacturing With Gerber File

♦ Why Are Gerber Files Important?​

✔ ​​Universal Acceptance​​ – Used by all PCB manufacturers worldwide.
✔ ​​Precision​​ – Ensures accurate reproduction of your PCB design.
✔ ​​Manufacturing Blueprint​​ – Tells the fab house how to produce the board.

♦ ​​​​​​Types of Gerber Files in a PCB Design​​:​

A complete PCB design typically includes these Gerber files:

    1. ​​Top/Bottom Copper Layer​​ (Signal traces)
    2. ​​Top/Bottom Solder Mask​​ (Protective coating)
    3. ​​Top/Bottom Silkscreen​​ (Component markings)
    4. ​​Drill File (Excellon format)​​ – Specifies hole sizes and locations.
    5. ​​Board Outline (Mechanical Layer)​​ – Defines PCB shape and cutouts.

♦ Technical Parameters

Item

Specification

Laers

1~64

Board thickness

0.1mm-7.0mm

Material

FR-4,CEM-1/CEM-3,PI,High Tg,Rogers

Max panel size

32"×48"(800mm×1200mm)

Min hole size

0.075mm

Min line width

3mil(0.075mm)

Surface finish

OSP,HASL,Imm Gold/Nickel/Ag, Electric gold

Copper thickness

0.5-7.0OZ

Soldermask

Green/Yellow/Black/White/Red/Blue

Silkscreen

Red/Yellow/Black/White

Min PAD

5mil(0.13mm)

Inter package

Vacuum

Outer package

Carton

Outline tolerance

±0.75mm

Hole tolerance

PTH:±0.05 NPTH:±0.025

Certificate

UL,ISO 9001,ISO14001,IATF16949

Special request

Blind hole+Gold finger + BGA

Material Suppilers

Shengyi, KB, Nanya, ITEQ,etc.

♦ One-Stop PCBs Solution
