High Frequency PCB PTFE 5G Base Station RF Module PCB Service
♦ What's High-Frequency PCB?
High-frequency PCB is a special circuit board designed for high-frequency electromagnetic scenes, suitable for high-frequency (frequency>300MHz, corresponding to wavelength <1 meter) and microwave (frequency>3GHz, corresponding to wavelength <0.1 meter) fields. It is based on microwave substrate copper clad laminate, combined with some processes of ordinary rigid circuit board manufacturing, or made through special processing.
♦ Advantages of High-Frequency PCB?
♦ Applications of High-Frequency PCB
♦ Technical Parameters
| Item | Specification |
| Laers | 1~32 |
| Board thickness | 0.1mm-7.0mm |
| Material | FR-4,CEM-1/CEM-3,PI,High Tg,Rogers |
| Max panel size | 32"×48"(800mm×1200mm) |
| Min hole size | 0.075mm |
| Min line width | 3mil(0.075mm) |
| Surface finish | OSP,HASL,Imm Gold/Nickel/Ag, Electric gold |
| Copper thickness | 0.5-7.0OZ |
| Soldermask | Green/Yellow/Black/White/Red/Blue |
| Silkscreen | Red/Yellow/Black/White |
| Min PAD | 5mil(0.13mm) |
| Inter package | Vacuum |
| Outer package | Carton |
| Outline tolerance | ±0.75mm |
| Hole tolerance | PTH:±0.05 NPTH:±0.025 |
| Certificate | UL,ISO 9001,ISO14001,IATF16949 |
| Special request | Blind hole+Gold finger + BGA |
| Material Suppilers | Shengyi, KB, Nanya, ITEQ,etc. |
